CPU |
CPU Model |
Intel® Core™ i7-1195G7 |
Intel® Core™ i5-1135G7 |
Intel® Core™ i3-1115G4 |
|
Graphic |
Intel® Iris® Xe Graphics, Up to 96 EUs,1.3Ghz |
Intel® Iris® Xe Graphics, Up to 80 EUs,1.3Ghz |
Intel® UHD Graphics, up to 48 EUs, 1.25Ghz |
|
TDP |
12 ~ 28W |
|
RAM |
2* non-ECC SO-DIMM Socket, support DDR4-3200 MHz, up to 64GB |
|
Storage |
M.2 |
1* M.2 (NGFF) 2280 M-key Slot, SATA3.0 by default, support PCIex4 Gen.4 NVMe SSD |
|
Supported OS |
Win 8, Win 10; Win 10 IoT, Ubuntu, Debian, Kali, CentOS, etc. |
|
I/O Interface |
COM |
3 * RS232 (COM1/2/3, Header, Full lanes)
2 * RS232/TTL (COM4/5, Header, 3 lanes)
1 * RS232/RS485/TTL (COM6, Header, 3 lanes)
Note: COM4/5/6 RS232/TTL sel by res, support RS232 by default. (COM4/5/6 must be used at the same mode) |
|
Ethernet |
2* Intel® GbE LAN (10/100/1000 Mbps, RJ45) |
|
USB |
6* USB3.0 |
|
Video |
2* HDMI(TYPE-A), max resolution up to 4096*2160@30Hz |
|
Audio |
1 * Line-Out + MIC 2in1 3.5mm Jack; 1 * Amplifer Header |
|
SIM |
1* Built-in nano-SIM Card Slot connected to M.2 B-key slot |
|
Power Supply |
12V DC; 1* DC 12V Power Input Thread Connector
(Optional 9-30V DC PWR module with Terminal Block (2-Pin, 5.08mm)) |
|
Other |
1* 8-bit GPIO header with 4 inputs and 4 outputs (optional) |
|
Expansion |
1* M.2 (NGFF) E-key Slot (PCIe+USB2.0, Support Wi-Fi+BT, 2230)
1* M.2 (NGFF) B-key Slot (PCIe/USB3.0+USB2.0, Support 5G+4G/3G, with 1* nano-SIM Card Slot, 3052) |
|
Operating Temperature |
-10 ~ 50 °C w/ 0.7m/s Airflow |
|
Storage Temperature |
-40 ~ 85 °C (-40~185 °F) |
|
Relative Humidity |
40 °C @ 95%, Non-Condensing |
|
Dimensions |
252* 44* 153 mm (W* H* D) |
|
Net Weight |
1.5 KG |
