Máy tính công nghiệp không quạt JHC Tech KMDA-3920-S001-I5 với Intel® Skylake-S/Kabylake-S LGA1151 CPU, H110 Chipset, 2*LAN, 7*USB, 4*COM, 2*PCI, HDMI, DP, VGA, 8-bit DIO, 1*I-port
KMDA-3920 là máy tính công nghiệp không quạt dạng hộp hiệu suất cao. Nó được trang bị CPU Intel® Celeron/ Pentium/ Core I3/ I5/I7 gen6/ 7th, 2 khe cắm RAM DDR4 2133/ 2400MHz, tối đa 32GB, 1 cổng DP, HDMI, VGA; 2 cổng GbE LAN, 4 cổng USB3.0, Mini PCIe hỗ trợ 4G và Wifi/BT; 2 card mở rộng PCI; 2 cổng 2.5″ SATA HDD/SSD, 1*mSATA, 1*M.2, dùng để lưu trữ. Với đầu vào nguồn rộng DC 12~24V, hiệu suất cao, nhiều IO, nhiều khe cắm mở rộng, dễ dàng tháo rời và lắp đặt thẻ chức năng hoặc HDD/SSD, được sử dụng rộng rãi cho AI thông minh, Bảo mật và Machine Vision.
Tính năng
- Aluminum chassis, SGCC frame
- Intel® Kabylake-S/Skylake-S CPU
- 2*DDR4 2400/2133MHz SODIMM, Up to 32GB
- DP+HDMI+VGA, Optional 3 independent displays
- 2*LAN, 4*USB3.0, 3*USB2.0, 4*COM, 8-bitDIO
- 2*PCI or PCIeX16 + PCIeX4 expansion
- 1*Mini PCIe(PCIe+USB), 1*M.2 2242 B-Key
- 1*mSATA, 2*2.5″ SATA, suppprt Raid0,1 (Q170)
- Support Intel® iVpro (Q170) and TPM2.0
- DC 12~24V Wide PowerInput
Thông số kỹ thuật
| CPU |
Gen.6th Intel® Skylake-S/gen.7th Intel® Kabylake-S Celeron/Pentium/Core I3/I5/I7 CPU, LGA 1151 socket |
| Chipset |
Intel® H110 (KMDA-3920-S001), Optional Intel® Q170 (KMDA-3920-S002) |
| System memory |
2*260-Pin SODIMM, dual channel DDR4 2133/2400MHz, up to 32GB |
| Expansion |
1*Full size Mini PCIe with PCIe +USBsignal and SIM slot, support 4G LTE/Wifi/BT wireless module
1*PCIe X16+1*PCIe X4 slots, support GTX 1660Ti GPU(Length is less than 225mm)
Optional 2*PCI Expansion, Support for installation of multiple function modules |
| Graphics |
Gen. 9th Intel®HD Graphics, HEVC/H265 HW HD en/decoder, DP1.2 max. res. 4096*2304@60Hz, HDMI1.4b max. res. 3840*2160@30Hz, VGA max. res. 1920*1200@60Hz, Optional 3 independent displays(In Intel® Q170 Chipset) |
| Audio |
Realtek ALC662VD controller, Audio out and MIC |
| LAN |
1*Intel I211AT+1*Intel I219LM PCIe Gig. Ethernet, 10/100/1000Mbps, support iVpro (Intel® Q170) |
| Storage |
2*2.5″ HDD/SSD bay, support RAID0/1 (In Intel® Q170 Chipset);
1*mSATA(SATA); 1*M.2 2242 B-key (SATA&USB) |
| DIO |
8-bit TTL signal, programmable input and output |
| I-port |
Optional 1*LPT, USB2.0, 16-bit DIO or Mini PCIe and M.2 I/O ports (such as serial ports) |
| I/O port |
2*RJ45 Gig-LAN(Front)
4*USB3.0 Type A (Front); 2*USB2.0 Type A(Front); 1*USB2.0 Type A(inside)
8-bit DIO, 2*5-pin terminal, 1*PS/2(Front)
2*RS232/422/485 DB9(Front), 2*RS232 DB9 (Front),
Audio-out and 1*MIC (Front)
1*HDMI +1*DP+1*VGA(Front) |
| LED |
1*Power LED, 1*HDD LED, 3*CPU term. LED (Red is warning , Yellow is high, Green is normal) |
| Control SW |
1*Power button, 1*2pin ter. power-on signal, 1*AT/ATXSelect SW, 1*Clear CMOS Select SW |
| Power supply |
DC 12~24V Input, 3-pin ter.connector(Front)
Consumption: 19V/3.62A (I7-6700T CPU, 4GB DDR4, 1TB HDD, with function module) |
| Watchdog timer |
Watchdog timeout programmable via software 1 to 255 second |
| OS |
Windows 7, Windows 10, Linux Fedora Ubuntu |
| Mechanical |
Aluminum chassis, SGCC frame |
| Color |
Silver grey |
| Mounting |
Desktop Mounting，Wall Mounting |
| Dimension |
(W*H*D): 220*250*131mm |
| Net weight |
5.27Kg |
| Operating temperature |
-20°C~65°C – Fanless with wide operating temp.SSD, airflow
-10°C~55°C – Fanless with HDD, airflow |
| Storage temperature |
-40°C~85°C |
| Storage humidity |
10~90%@40°C, Non-condensing |
| Vibration |
5grms/5~500Hz/random/in working (SSD); 1grms/5~500Hz/random/in working (HDD) |
| Shock |
50g peak acceleration(11ms duration)(SSD); 20g peak acceleration(11ms duration)(HDD） |
| EMC and Certification |
CE/FCC Class B |
Thông tin đặt hàng
Embedded Box Computer, I5-6500 CPU, H110 Chipset, 8GB DDR4, 2*LAN, 4*USB3.0, 3*USB2.0, 4*COM, 1*Mini PCIe, 2*PCI, 1*HDMI, 1*DP, 1*VGA, Audio out, Mic, 8-bit DIO, 1*PS/2, 1*I-port, 2*2.5″ SATA bay, 1*M.2, 1*mSATA, DC 12~24V, TPM2.0
