CPU
|
ARM Rockchip
|
RK3588, Quad-core Cortex-A76 + Quad-core Cortex-A55
|
RK3576, Quad-core Cortex-A72 + Quad-core Cortex-A53
|
RK3568, Quad-core Cortex-A55, Clock speed up to 2.0GHz
|
|
RAM
|
Type
|
SDRAM LPDDR4X Memory on board
|
SDRAM LPDDR5 Memory on board
|
SDRAM LPDDR4X Memory on board
|
|
|
Capacity
|
8GB/ 16GB
|
4GB/8GB
|
4GB/8GB
|
|
Storage
|
eMMC 5.1
|
64G/ 128GB
|
32G/ 64GB
|
32G/ 64GB
|
|
Form Factor
|
1* TF Card
|
1* TF Card
|
2* SATA3.0 7P Connector; 1* TF Card Slot
|
|
M.2
|
1* M.2 B-Key 2242/3052, PCIe x1/USB3.0/SATA, Support 5G/4G/ NVMe/SATA SSD
|
|
Supported OS
|
Android 11, Linux (Ubuntu, Debian, Kali, CentOS, etc.)
|
Android 14, Linux (Ubuntu, Debian, Kali, CentOS, etc.)
|
Android 11, Linux (Ubuntu, Debian, Kali, CentOS, etc.)
|
|
I/O Interface
|
COM
|
2* RS232/RS485 (COM1/2); 4* RS232, 2-wire (COM3-6)
|
|
Ethernet
|
1* Realtek RTL8211F GbE Ethernet Controller;
1* Realtek RTL8211H GbE Ethernet Controller;
|
2* Realtek RTL8211F -CG GbE Ethernet Controller
|
2 * Realtek GBE LAN Chip (RJ45, 10/100/1000 Mbps)
|
|
USB
|
1* USB3.0/ OTG;
3 * USB3.0
|
1* USB3.0/ OTG ; 3 * USB3.0
|
1 * USB3.0/OTG;
3 * USB2.0;
|
|
CANBus
|
2* CANBus header, support CAN FD, CANBus 2.0 (Optional)
|
|
Video
|
1* HDMI, max 1920*1080@60Hz;
|
1* HDMI, max 8K@60Hz
|
1* HDMI, max 4096×2304@60Hz
|
|
Audio
|
2* Wafer, L/R Amplifier;
1* Wafer, Lin-out + MIC;
|
|
SIM
|
1* SIM Crad for Mini-PCIe and M.2 key-B
|
1, SIM1 Card Wafer, connected to Mini-PCIe;
1, Nano SIM1 Slot, connected to Mini-PCIe;
|
1* Mini-PCIe Slot with 1* External Nano SIM card slot/ 1* Internal SIM card slot
|
|
Power Supply
|
12V DC; 1* DC Jack (5.5* 2.5mm); Optional 9-36VDC Power Input with Terminal Block (2-Pin, 5.08mm)
|
|
Other
|
8 * GPIO; 1 * Recovery Button; 1 * Power Button Header; 1 * System Reset Header; 1 * Power LED Header
|
|
Expansion
|
1 * M.2 (NGFF) Key-B Slot (PCIE 3.0/PCIE2.0/USB3.0/SATA, 2242/3052);
1* Mini-PCIe, support PCIe x1/SATA/USB2.0
Support WiFi, 4G, 5G, CANBus
|
|
Operating Temperature
|
-10 ~ 70 °C w/ 0.7m/s Airflow
|
|
Storage Temperature
|
-40 ~ 85 °C (-40~185 °F)
|
|
Relative Humidity
|
40 °C @ 95%, Non-Condensing
|
|
Dimensions
|
192* 67* 145 mm (W* H* D)
|
|
Net Weight
|
2.1 KG
|
