CPU
|
CPU Model
|
Intel® Celeron® J1900
|
11th Gen. Intel® Core™ Processo
|
|
TDP
|
10W
|
Up to 28W
|
|
RAM
|
Type & Qty
|
1* SO-DIMM Socket
|
2* SO-DIMM Socket
|
|
|
Frequency
|
DDR3L-1333/1600 MHz, Up to 8GB
|
DDR4-3200 MHz, Up to 64GB
|
|
Storage
|
mSATA
|
1* mSATA3.0 slot (6Gb/s); (Intel® Celeron® J1900 supports mSATA2.0, 3Gb/s)
|
|
SATA
|
1* 2.5″ SATA3.0 (6Gb/s); (Intel® Celeron® J1900 supports SATA2.0, 3Gb/s)
|
|
Supported OS
|
Win 7, Win 8, Win 10, Win11, Linux (Ubuntu, CentOS, etc.); WES 7; Win 10 IoT
|
|
I/O Interface
|
COM
|
4* Isolated DB9 COM Ports (COM1-4, support RS232/485, switchable by jumper)
|
|
Ethernet
|
2* 1.0 GbE LAN, Intel i211/i210, RJ45
|
2* 2.5 GbE LAN, Intel i225, RJ45
|
|
USB
|
1* USB3.0 + 5* USB2.0
|
2* USB3.0; 4* USB2.0
|
|
Video
|
1* HDMI, Support 4096×2304@24Hz;
1* VGA, Support 1920×1200@60Hz;
|
1* HDMI, Support 4096×2304@60Hz;
1* VGA, Support 1920×1200@60Hz;
|
|
Audio
|
1* MIC, 1* SPK; With 5.1 channels HD Audio Codec Realtek ALC662
|
1* MIC, 1* SPK; With 7.1 channels HD Audio Codec Realtek ALC897
|
|
SIM
|
1* External SIM card slot connected to M.2 B-key slot
|
1* External SIM card slot connected to M.2 B-key slot
|
|
Power Supply
|
9-36V DC; 1* Terminal Block (3-Pin, 5.08mm), 1* DC Jack (5.5* 2.5mm)
|
|
Other
|
1* 8-bit GPIO, Terminal Block (12-Pin, 3.81mm), 4-Inputs/4-Outputs, 0-5V Input Range;
1* Terminal Block (4-Pin, 3.81mm Pitch) with Remote Switch and Power Indicator;
1* Auto-On Switch; 1* PS/2
|
|
Expansion
|
1* M.2 3052 B-key slot connected to SIM card slot (PCIe+USB2.0, the USB2.0 signal is shared with one of USB2.0 on front panel)
|
1* M.2 3052 B-key slot connected to SIM card slot (PCIe+USB2.0, the USB2.0 signal is shared with one of USB2.0 on front panel)
1* Full Size Mini-PCIe (PCIe+USB2.0);
|
|
Operating Temperature
|
-10 ~ 55 °C w/ 0.7m/s Airflow
|
|
Storage Temperature
|
-40 ~ 85 °C (-40~185 °F)
|
|
Relative Humidity
|
40 °C @ 95%, Non-Condensing
|
|
Dimensions
|
192* 67* 165.43 mm (W* H* D)
|
|
Net Weight
|
2.5 KG
|
