Processor system |
Jetson Orin NX |
NVIDIA® Jetson Orin™ NX 16GB |
NVIDIA® Jetson Orin™ NX 8GB |
|
CPU |
8-core Arm® Cortex-A78AE® v8.2 64-bit CPU 2MB L2 + 4MB L3, max frequency up to 2.0GHz |
6-core Arm® Cortex-A78AE® v8.2 64-bit CPU 1.5MB L2 +4MB L3, max frequency up to 2.0GHz |
|
GPU |
32-core NVIDIA Ampere architecture GPU with 1024 Tensor Cores |
|
|
Memory |
16GB 128-bit LPDDR5 102.4GB/s |
8GB 128-bit LPDDR5 102.4GB/s |
|
|
AI Performance |
With JP5.x.x, Sparse 100 INT8 TOPs; Dense 50 INT8 TOPs With JP6.2, Sparse 157 INT8 TOPs; Dense 78 INT8 TOPs |
With JP5.x.x, Sparse 70 INT8 TOPs; Dense 35 INT8 TOPs With JP6.2, Sparse 117 INT8 TOPs; Dense 58 INT8 TOPs |
|
|
DL Accelerator |
2x NVDLA v2 |
1x NVDLA v2 |
|
|
Video Encoding |
1x 4K60 (H.265); 3x 4K30 (H.265); 6x 1080p60 (H.265); 12x 1080p30 (H.265) |
|
|
Video Decoding |
1x 8K30 (H.265); 2x 4K60 (H.265); 4x 4K30 (H.265); 9x 1080p60 (H.265); 18x 1080p30 (H.265) |
|
Storage |
M.2 |
1* M.2 Key-M 2280 (PCIe x4), Support PCIe x4 NVMe SSD |
|
Supported OS |
Linux(Ubuntu 22.04, Ubuntu 20.04), with NVIDIA BSP JetPack Above 5.1 (JP6.2 version is optional) |
|
I/O Interface |
COM |
2* RS232/RS485 (J_COM1/2, Wafer); 1* RS232/TTL (J_COM3, Wafer) |
|
Ethernet |
2* Intel i210 GbE LAN; 1* Realtek GbE LAN |
|
USB |
4* USB 3.0 (TYPE-A, External IO); 1* USB 2.0 (Internal Micro USB, OTG) |
|
Video |
1* HDMI 2.1, which supports a maximum resolution of 4096 x 2304@60Hz |
|
SIM |
Nano SIM 1 connected to Mini-PCIe, support Wi-Fi + 4G/3G;
Nano SIM 2 connected to M.2 Key-B 3042/3052, support 4G/5G wireless |
|
CAN |
1* CANBus, support CANFD, CAN1.0, CAN2.0, digital capacitive isolation |
|
GPIO |
On-board 16-channel DIO (0-5VDC);
(Optional 16-channel DI/DO opto-isolated module (8* DI + 8* DO, 5-24VDC, 2A, Digital IO or Analog IO) |
|
Power supply |
12V-28VDC, 1* Terminal Block (4-Pin, 5.08mm) |
|
Other |
1* Restart Button; |
|
Expansion |
1 *M.2 Key-B 3042/3052 Slot (USB3.0+USB2.0, Support 4G/5G, with Nano SIM2 Card Slot);
1 *Mini-PCIe Slot (PCIE + USB2.0, Support WIFI+4G/3G, with Nano SIM1 Card Slot);
On-board Realtek Wireless+Bluetooth module (1 * Micro RF Connector, supports Wi-Fi 2.4/5GHz & Bluetooth 4.2) |
|
Operating Temperature |
-10 ~ 60 °C w/ 0.7m/s Airflow |
|
Storage Temperature |
-40 ~ 85 °C (-40~185 °F) |
|
Relative Humidity |
40 °C @ 95%, Non-Condensing |
|
Dimensions |
290.35* 81.54* 165.5 mm (W* H* D) |
|
Net Weight |
2.5 KG |
