| Supported OS |
Linux(Ubuntu 20.04), with NVIDIA BSP JetPack Above 5.3.1 (JP6.2 version is still on processing) |
| Processor System |
Jetson Orin NX |
NVIDIA® Jetson Orin™ NX 16GB |
NVIDIA® Jetson Orin™ NX 8GB |
| CPU |
8-core Arm® Cortex-A78AE® v8.2 64-bit CPU 2MB L2 + 4MB L3, max frequencyup to 2.0GHz |
6-core Arm® Cortex-A78AE® v8.2 64-bit CPU 1.5MB L2 +4MB L3, max frequencyup to 2.0GHz |
| GPU |
32-core NVIDIAAmpere architecture GPU with 1024 Tensor Cores |
| Memory |
16GB 128-bit LPDDR5 102.4GB/s |
8GB 128-bit LPDDR5 102.4GB/s |
| AI Performance |
With JP5.x.x, Sparse 100 INT8 TOPs; Dense 50 INT8 TOPs With JP6.2, Sparse 157 INT8 TOPs; Dense 78 INT8 TOPs |
With JP5.x.x, Sparse 70 INT8 TOPs; Dense 35 INT8 TOPs With JP6.2, Sparse 117 INT8 TOPs; Dense 58 INT8 TOPs |
| DL Accelerator |
2x NVDLA v2 |
Ix NVDLA v2 |
| Video Encoding |
1x 4K60 (H.265); 3x 4K30 (H.265); 6x 1080p60 (H.265); 12x 1080p30 (H.265) |
| Video Decoding |
1x 8K30 (H.265); 2x 4K60 (H.265); 4x 4K30 (H.265); 9x 1080p60 (H.265); 18x 1080p30 (H.265) |
| Storage |
M.2 |
1* M.2 Key-M 2280 (PCIe x4), Support PCIe x4 NVMe SSD |
| I/O Interface |
COM |
2* RS232/RS485 (J_COM1/2, Wafer); 1* RS232/TTL (J_COM3, Wafer); |
| Ethernet |
2* Intel i210 GbE LAN; 1* Realtek GbE LAN; |
| USB |
4* USB 3.0 (TYPE-A, External IO); 1* USB 2.0 (Internal Micro USB, OTG); |
| Video |
1* HDMI 2.1, which supports a maximum resolution of 4096 x 2304@60Hz; |
| SIM |
Nano SIM 1 connected to Mini-PCIe, support Wi-Fi + 4G/3G; Nano SIM 2 connected to M.2 Key-B 3042/3052, support 4G/5G wireless; |
| CAN |
1* CANBus, support CANFD, CAN1.0, CAN2.0, digital capacitive isolation |
| GPIO |
On-board 16-channel on-board configurable GPIO; Optional 16-channel DI/DO opto-isolated module (8*DI + 8*DO, DC 5-24V, 2A, switch/analog modes); |
| Featured Interfaces |
1* Restart Button; |
| Power Supply |
DC 12V-28V; 2-PIN 5.08mm green connector |
| Extended Capabilities |
Additional Internal Interface |
1 *M.2 Key-B 3042/3052 Slot (USB3.0+USB2.0, Support 4G/5G, with Nano SIM2 Card Slot); 1 *Mini-PCIe Slot (PCIE + USB2.0, Support WIFI+4G/3G, with Nano SIM1 Card Slot); On-board Realtek Wireless+Bluetooth module (1 * Micro RF Connector, supports Wi-Fi 2.4/5GHz & Bluetooth 4.2); |
| Environment |
Operating Temp. |
-10 ~ 60°C |
| Storage Temp. |
-40 ~ 85°C (-40~185 °F) |
| Relative Humidity |
40°C @95%, Non-Condensing |
| Physical Characteristics |
Dimensions |
152.4* 49.9 * 112.3 mm (W* H* D) |
| Net Weight |
1.7 KG |
