| Standard & Protocol |
IEEE 802.3 for 10Base-T
IEEE802.3u for 100Base-TX
IEEE 802.3ab for 1000Base-T
IEEE802.11a/b/g/n/ac/ax for WLAN
IEEE802.11i for wireless security
IEEE802.11r for fast roaming
IEEE802.11e for WWM
IEEE802.3af for PoE
IEEE802.3at for PoE+ |
| Working mode |
Routing mode (WAN: PPPoE dial-up, static IP, DHCP dynamic IP acquisition)
AP mode (LAN: static IP, DHCP dynamically acquiring IP)
Bridge mode (connection: WDS bridge, universal bridge; point-to-point, roaming)
Client mode (connection: WDS bridge, universal bridge, wireless NAT; point-to-point, roaming) |
| WLAN |
WAP/WAP2/WAP3 personal/enterprise edition encryption mode, hidden wireless SSID, wireless user isolation, wireless transmission power adjustment, maximum user limit, packet segmentation and RTS threshold, China/US wireless channel, WMM |
| Management |
Intranet settings, extranet settings, wireless settings, AC management, SNMP management, roaming agent, user settings, system upgrade, timed restart, profile management, system log, wireless user list, and Wi-Fi real-time traffic monitoring |
| Security policy |
Wireless user black/white list, wireless user event notice, IP filtering, MAC filtering, port forwarding, port redirection, ARP binding, DMZ setting |
| Routing/switching |
Static routing (routing mode, wireless NAT) |
| Location Service |
Wireless probe |
| Troubleshooting |
Network Detection |
| Time Management |
NTP Client |
| Radio Frequency |
802.11b/g/n/ax: 2.412GHz~2.4835GHz
802.11a/n/ac/ax: 5.18GHz~5.825GHz
RF power output: 20dBm
Modulation methods: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM |
| Receiving Sensitivity |
802.11b: -87dBm@1Mbps, -76dBm@11Mbps
802.11g/a: -82dBm@6Mbps, -65dBm@54Mbps
802.11n: -82dBm@MCS0, -64dBm@MCS7
802.11ac: -82dBm@MCS0, -57dBm@MCS9
802.11ax: -82dBm@MCS0, -52dBm@MCS11 |
| Transmitting power |
802.11b: 24dBm@1Mbps, 20dBm@11Mbps
802.11g/a: 24dBm@6Mbps, 20dBm@54Mbps
802.11n: 24dBm@MCS0, 20Bm@MCS7
802.11ac: 24dBm@MCS0, 20Bm@MCS9
802.11ax: 24dBm@MCS0, 20Bm@MCS11 |
| Interface |
Gigabit RJ45 port (LAN): 1 10/100/1000Base-T(X) self-adaptive RJ45 LAN port, support automatic flow control, full/half duplex mode, MDI/MDI-X self-adaption
Gigabit RJ45 port (LAN/WAN): 1 10/100/1000Base-T(X) self-adaptive RJ45 LAN/WAN port, supports automatic flow rate control, full/half duplex, MDI/MDI-X self-adaption; supports IEEE802.3af/at standard PoE power input
Antenna interface: two 2.4G antenna interfaces, N-K(Female)
Two 5G antenna interfaces, N-K(Female) |
| Power Supply |
Gigabit PoE RJ45 port: supports IEEE802.3af/at standard, PoE 48VDC power input
Power supply terminal: 12~48VDC power input, support non-polarity, using 3-pin 5.08mm pitch terminal blocks with waterproof plug |
| Indicator |
Running indicator, 2.4G indicator, 5.8G indicator, WLAN indicator, LAN indicator, bridge signal strength indicator |
| Power Consumption |
No-load: 5.7W@24VDC
Full-load: 7.9W@24VDC (high temperature≤8.6W) |
| Working Environment |
Operating temperature: -40~75℃
Storage temperature:-40~85℃
Relative humidity: 5%～95% (no condensation) |
| Physical Characteristic |
Housing: IP68 protection grade
Installation: Wall mounting or pole mounting
Dimension (W x H x D): 275mm×245mm×76mm |
| Industrial Standard |
IEC 61000-4-2 (ESD, electrostatic discharge), Level 4
Air discharge:± 15kV
Contact discharge: ±8kV
IEC 61000-4-4 (EFT, electrical fast transient), Level 4
Power supply: ±4kV
Ethernet port: ±2kV
IEC 61000-4-5 (Surge), Level 4
Power supply: common mode±4kV, differential mode±2kV
Ethernet interface: ±4kV
Shock: IEC 60068-2-27
Free fall: IEC 60068-2-32
Vibration: IEC 60068-2-6 |
| Authentication |
CE, FCC, RoHS |
