Standard & Protocol |
IEEE 802.3 for 10Base-T
IEEE802.3u for 100Base-TX
IEEE 802.3ab for 1000Base-T
IEEE 802.3z for 1000Base-X
IEEE802.11a/b/g/n/ac/ax for WLAN
IEEE802.11i for wireless security
IEEE802.11r for fast roaming
IEEE802.11e for WWM |
|
Working Mode |
Routing mode (WAN: PPPoE dial-up, static IP, DHCP dynamic IP acquisition)
AP mode (LAN: static IP, DHCP dynamically acquiring IP)
Bridge mode (connection: WDS bridge, universal bridge; point-to-point, roaming)
Client mode (connection: WDS bridge, universal bridge, wireless NAT; point-to-point, roaming) |
|
WLAN |
Encryption mode of WAP/WAP2/WAP3 personal edition and WPA2/WPA3 enterprise edition, hidden wireless SSID, wireless user isolation, wireless transmission power adjustment, maximum user limit, RTS threshold, China/US wireless channel, WMM |
|
Management |
Intranet settings, extranet settings, wireless settings, AC management, SNMP management, QoS management, AP roaming control, roaming agent, user settings, system upgrade, timed restart, profile update, system log, wireless user list, and Wi-Fi real-time traffic monitoring, log management, time settings, access settings and diagnostic Tools |
|
Security Policy |
Wireless user black/white list, wireless user event notice, IP filtering, MAC filtering, URL filtering, port forwarding, port redirection, ARP binding, DMZ settings, access settings |
|
Routing/Switching |
Static routing (routing mode, wireless NAT) |
|
Location Service |
Wireless probe |
|
Troubleshooting |
Network Detection |
|
Time Management |
NTP Client |
|
Radio Frequency |
802.11b/g/n/ax: 2.412GHz~2.4835GHz
802.11a/n/ac/ax: 5.18GHz~5.825GHz
RF power output: 20dBm
Modulation methods: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM |
|
Receiving Sensitivity |
802.11b: -87dBm@1Mbps, -76dBm@11Mbps
802.11g/a: -82dBm@6Mbps, -65dBm@54Mbps
802.11n: -82dBm@MCS0, -64dBm@MCS7
802.11ac: -82dBm@MCS0, -57dBm@MCS9
802.11ax: -82dBm@MCS0, -52dBm@MCS11 |
|
Transmitting Power |
802.11b: 23dBm@1Mbps, 20dBm@11Mbps
802.11g/a: 23dBm@6Mbps, 20dBm@54Mbps
802.11n: 23dBm@MCS0, 18dBm@MCS7
802.11ac: 23dBm@MCS0, 18dBm@MCS9
802.11ax: 23dBm@MCS0, 18dBm@MCS11 |
|
Interface |
Gigabit copper port: 1 10/100/1000Base-T(X) RJ45 port is LAN port
Gigabit SFP: 1 1000Base-X SFP slot, which is LAN/WAN port
Antenna interface: 2 2.4G/5G dual-frequency SMA-K antenna interfaces
Console port: CLI command management port(RS-232), using 3-pin 2.54mm pitch terminal blocks |
|
Power Supply |
9~24VDC, support anti-reverse connection and slow start-up, using 3-pin 5.08mm pitch terminal blocks |
|
Indicator |
Power indicator, running indicator, alarm indicator, 2.4G indicator, 5.8G indicator, bridge signal strength indicator, interface indicator |
|
Power Consumption and Current |
|
Temperature |
Transmission
Power
(dBm) |
Voltage
(VDC) |
Start-up current
(A) |
Power Consumption of Full Mean Load
(W) |
Power Consumption of Full Peak Load
(W) |
|
Normal Temperature
(25℃) |
20 |
9 |
0.549 |
11.612 |
15.921 |
|
12 |
0.407 |
11.251 |
14.628 |
|
18 |
0.278 |
11.105 |
15.174 |
|
24 |
0.200 |
11.079 |
15.672 |
|
27 |
9 |
0.560 |
13.247 |
18.243 |
|
12 |
0.419 |
12.919 |
21.156 |
|
18 |
0.286 |
12.834 |
22.716 |
|
24 |
0.217 |
12.956 |
20.136 |
|
High temperature
(75℃) |
20 |
9 |
0.601 |
12.148 |
15.921 |
|
12 |
0.448 |
11.800 |
15.54 |
|
18 |
0.302 |
11.756 |
14.796 |
|
24 |
0.232 |
11.796 |
15.912 |
|
27 |
9 |
0.694 |
14.170 |
18.243 |
|
12 |
0.444 |
13.446 |
20. 952 |
|
18 |
0.299 |
13.370 |
20.592 |
|
24 |
0.228 |
13.350 |
24.12 |
|
|
Working Environment |
Operating temperature: -40~75℃
Storage temperature:-40~85℃
Relative humidity: 5%～95% (no condensation) |
|
Physical Characteristic |
Shell: null
Installation: embedded mounting
Dimension (W x H x D): 85mm×14.7mm×138mm
Weight: 0.17kg |
|
Authentication |
CE, FCC, RoHS |
