Standard & Protocol |
IEEE 802.3 for 10Base-T
IEEE802.3u for 100Base-TX
IEEE802.11b/g/n/a/ac for WLAN
IEEE802.11i for wireless security
IEEE802.11r for fast roaming
IEEE802.3af/at for PoE/PoE+ |
|
Working Mode |
Route mode, AP mode, bridge mode, client mode |
|
Network Settings |
Intranet Settings, External Network Settings, Wireless Settings, Wireless Probe, AC Management, SNMP Management, QoS Management, Roaming Agent |
|
Wireless Client |
User list, user event |
|
Firewall
(Route mode/Wireless NAT) |
IP filtering, MAC filtering, URL filtering, port forwarding, Port redirection, ARP binding, DMZ settings |
|
System Tools |
Network detection, User settings, System upgrading, System Restart, System log |
|
Radio Frequency |
802.11b/g/n:2.412GHz~2.4835GHz
802.11ac/n/a:5.18GHz~5.825GHz
RF power output: 20dBm
Modulation methods: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM |
|
Receiving Sensitivity |
802.11n_HT40:-82dBm@MCS0, -64dBm@MCS7
802.11n_HT20:-85dBm@MCS0, -67dBm@MCS7
802.11g/a:-91dBm@6Mbps, -72dBm@54Mbps
802.11b:-93dBm@1Mbps, -87dBm@11Mbps
802.11ac:-84dBm@MCS0, -59dBm@MCS9 |
|
Transmitting Power |
802.11n_HT40:20dBm@MCS0, 20dBm@MCS7
802.11n_HT20:20dBm@MCS0, 20dBm@MCS7
802.11g/a:20dBm@6Mbps, 20dBm@54Mbps
802.11b:20dBm@1Mbps, 20dBm@11Mbps
802.11ac:20dBm@MCS0, 20dBm@MCS9 |
|
Interface |
WAN port: 1 10/100 Base-T(X) RJ45port, support POE 48VDC power supply input
LAN port: 4 10/100Base-T(X) RJ45 ports
Antenna: 2 2.4G RP-SMA-K (Female) interfaces
2 5.8G RP-SMA-K (Female) interfaces
Console port: CLI command management port(RS-232), RJ45 |
|
Power Supply |
12~48VDC dual power supply redundancy, support non-polarity, 4-pin 5.08mm pitch terminal block;
WAN port supports PoE 48VDC power supply input |
|
Indicator |
Running indicator, Alarm indicator, Power indicator, 2.4G indicator, 5.8G indicator, WLAN bridge signal strength indicator, PoE indicator |
|
Power Consumption |
No-load: 3.0W@24VDC
Full-load: 7.9W@24VDC(high temperature) |
|
Working Environment |
Operating temperature: -40~75℃
Storage temperature:-40~85℃
Relative humidity: 5%～95%(no condensation) |
|
Physical Characteristic |
Housing: IP40 protection, metal
Installation: DIN-Rail mounting
Weight: 0.57kg
Dimension (W x H x D): 35mm×150mm×120mm |
|
Industrial Standard |
IEC 61000-4-2 (ESD, electrostatic discharge), Level 3
- Air discharge: ±8kV
- Contact discharge: ±6kV
IEC 61000-4-4 (EFT, electrical fast transient pulses), Level 3
- Power supply: ±2kV
- Ethernet port: ±1kV
IEC 61000-4-5 (Surge), Level 3
- Power supply: common mode±2kV, differential mode±1kV
- Ethernet port: ±2kV
Shock: IEC 60068-2-27
Free fall: IEC 60068-2-32
Vibration: IEC 60068-2-6 |
|
Authentication |
CE, FCC, RoHS |
