Standard & Protocol |
IEEE 802.3 for 10Base-T
IEEE802.3u for 100Base-TX
IEEE 802.3ab for 1000Base-T
IEEE802.11a/b/g/n/ac/ax for WLAN
IEEE802.11i for wireless security
IEEE802.11r for fast roaming
IEEE802.11e for WWM
IEEE802.3af for PoE
IEEE802.3at for PoE+ |
|
Working Mode |
Routing mode (WAN:PPPoE dial-up, static IP, DHCP dynamic IP acquisition)
AP mode (LAN: static IP, DHCP dynamically acquiring IP)
Bridge mode (connection: WDS bridge, universal bridge; point-to-point, roaming)
Client mode (connection: WDS bridge, universal bridge, wireless NAT; point-to-point, roaming) |
|
WLAN |
WAP/WAP2/WAP3 personal/enterprise edition encryption mode, hidden wireless SSID, wireless user isolation, wireless transmission power adjustment, maximum user limit, packet segmentation and RTS threshold, China/US wireless channel, WMM |
|
Management |
Intranet settings, extranet settings, wireless settings, AC management, SNMP management, QoS management, AP roaming control, roaming agent, user settings, system upgrade, timed restart, profile update, system log, wireless user list, and Wi-Fi real-time traffic monitoring, log management, time settings, access settings and diagnostic Tools |
|
Security Policy |
Wireless user black/white list, wireless user event notice, IP filtering, MAC filtering, URL filtering, port forwarding, port redirection, ARP binding, DMZ settings, access settings |
|
Routing/switching |
Static routing (routing mode, wireless NAT) |
|
Location Service |
Wireless probe |
|
Trouble Shooting |
Network detection, Ping test, route tracing |
|
Time Management |
NTP Client |
|
Radio Frequency |
802.11B/g/n: 2.412GHz~2.4835GHz
802.11Ac/n/a: 5.18GHz~5.825GHz
RF power output: 27dBm
Modulation methods: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM |
|
Receiving Sensitivity |
802.11b: -87dBm@1Mbps,-76dBm@11Mbps
802.11g/a: -82dBm@6Mbps,-65dBm@54Mbps
802.11n: -82dBm@MCS0,-64dBm@MCS7
802.11ac: -82dBm@MCS0,-57dBm@MCS9
802.11ax: -82dBm@MCS0,-52dBm@MCS11 |
|
Transmitting Power |
802.11b: 24dBm@1Mbps,20dBm@11Mbps
802.11g/a: 24dBm@6Mbps,20dBm@54Mbps
802.11n: 24dBm@MCS0,20Bm@MCS7
802.11ac: 24dBm@MCS0,20Bm@MCS9
802.11ax: 24dBm@MCS0,20Bm@MCS11 |
|
Interface |
Gigabit RJ45 port (LAN): 4 10/100/1000Base-T(X) self-adaptive RJ45 LAN port, support automatic flow control, full/half duplex mode, MDI/MDI-X self-adaption
Gigabit RJ45 port (LAN/WAN): 1 10/100/1000Base-T(X) self-adaptive RJ45
LAN/WAN port,
supports automatic flow rate control, full/half
duplex, MDI/MDI-X self-adaption;
supports IEEE802.3af/at standard PoE
power input
Antenna interfaces: 2 2.4/5G combined antenna interfaces, adopting RPSMA-K connector
Console port: CLI command management port(RS-232)
Relay (Reserved): one relay output, and adopts 6-pin 5.08mm pitch terminal blocks, with the relay occupying two pins |
|
Power Supply |
Gigabit PoE RJ45 port: supports IEEE802.3af/at standard, PoE 48VDC power input
Power supply terminal: 12~48VDC power input, support non-polarity,
using 6-pin 5.08mm pitch terminal blocks, with
power supply occupies 4 pins |
|
Indicator |
Running indicator, alarm indicator, power indicator, 2.4G indicator, 5.8G indicator, 2.4G/5G bridge signal strength indicator, WAN indicator, LAN indicator, PoE indicator |
|
Power Consumption |
Normal temperature No-load
9.2w@12VDC, 8.3w@24VDC, 8.2w@36VDC, 8.8w@48VDC
Normal temperature full load
21.6w@12VDC, 18.0w@24VDC, 19.0w@36VDC, 18.7w@48VDC
High temperature full load
22.3w@12VDC, 19.0w@24VDC, 18.7w@36VDC, 18.9w@48VDC |
|
Working Environment |
Operating temperature: -40~75℃
Storage temperature:-40~85℃
Relative humidity: 5%～95%(no condensation) |
|
Physical Characteristic |
Housing: IP40 protection grade
Installation: DIN-Rail or wall mounting
Dimension (W x H x D): 53mm×138mm×110mm
Weight: 741g |
|
Industrial Standard |
IEC 61000-4-2 (ESD, electrostatic discharge), Level 4
- Air discharge:± 15kV
- Contact discharge: ±8kV
IEC 61000-4-4 (EFT, electrical fast transient), Level 4
- Power supply: ±4kV
- Ethernet interface: ±2kV
IEC 61000-4-5 (Surge), Level 4
- Power supply: common mode±4kV, differential mode±2kV
- Ethernet interface: ±4kV
Shock: IEC 60068-2-27
Free fall: IEC 60068-2-32
Vibration: IEC 60068-2-6 |
|
Authentication |
CE, FCC, RoHS |
