Standards and protocols |
10Base-T, compliant with IEEE 802.3
100Base-TX, compliant with IEEE 802.3u
1000Base-T, compliant with IEEE 802.3ab
1000Base-X, compliant with IEEE 802.3z
10GBase-X, compliant with IEEE802.3ae
Spanning tree, compliant with IEEE 802.1D
Rapid spanning tree, compliant with IEEE 802.1w
Multiple spanning trees, compliant with IEEE 802.1s
Service, compliant with IEEE 802.1p
VLAN, compliant with IEEE 802.1Q
Flow control, compliant with IEEE 802.3x
Asymmetric flow control, compliant with IEEE 802.3z
Link aggregation, compliant with IEEE 802.3ad |
|
MAC Switching |
Support static configuration and dynamic learning of MAC addresses
Support viewing and clearing MAC address
MAC address aging time is configurable
Support MAC address learning quantity limit
Support MAC address filtering function
Support IEEE 802.1AE MacSec security control |
|
VLAN |
Support 4K VLAN entries
Support GVRP
Support QinQ function
Support Private VLAN
Support voice valn |
|
Ring network protection |
Support 802.1D (STP), 802.1W (RSTP), 802.1S (MSTP)
Support BPDU protection, root protection, loop protection
Support EAPS Ethernet link automatic protection protocol
Support ERPS Ethernet ring network protection protocol |
|
Multicast |
Support IGMP v1/v2/v3
Support IGMP Snooping
Support IGMP Fast Leave
Support multicast group strategy and multicast group quantity limit
Support multicast traffic replication across VLANs |
|
IP Routing |
Support ipv4/ipv6 dual stack protocol
Support static routing
Support RIP v1/v2, OSPF dynamic routing
Support VRRP virtual routing |
|
IPv6 |
Support ICMPv6, DHCPv6, ACLv6, IPv6 Telnet
Support IPv6 neighbor discovery
Support Path MTU discovery
Support MLD v1/v2
Support MLD Snooping |
|
DHCP |
Support DHCP Server
Support DHCP Relay
Support DHCP Client
Support DHCP Snooping |
|
ACL |
Support Layer 2, Layer 3, and Layer 4 ACL
Support IPv4 and IPv6 ACL
Support VLAN ACL |
|
QoS |
Support traffic classification based on each field of L2/L3/L4 protocol header
Support CAR traffic restriction
Support 802.1P/DSCP priority re-marking
Supports queue scheduling modes such as SP, WRR, SP+WRR, etc.
Support congestion avoidance mechanisms such as Tail-Drop and WRED
Support traffic monitoring and traffic shaping |
|
Virtualization |
Support vss virtualization |
|
Safety Features |
Support ACL flow identification and filtering security mechanism based on L2/L3/L4
Supports protection against DDoS attacks, TCP SYN Flood attacks, UDP Flood attacks, etc.
Supports suppression of multicast, broadcast, and unknown unicast messages
Support port isolation
Support port security, IP+MAC+port binding
Support DHCP sooping, DHCP option82
Support IEEE 802.1x authentication
Support Radius, Tacacs+ authentication
Support command line hierarchical protection |
|
reliability |
Support static/LACP link aggregation
Support UDLD unidirectional link detection
Support Ethernet OAM
Support ISSU service without interrupting system upgrade |
|
Management and maintenance |
Support Console, Telnet, SSH 2.0
Support ZTP Zero Touch Provisioning
Support browser-based WEB management
Support SNMP v1/v2/v3
Support TFTP file upload and download management
Support RMON event history record |
|
Green and Energy Saving |
Support IEEE 802.3az Green Energy Efficient Ethernet |
|
power supply |
100~240VAC, 50Hz±10% |
|
Work Environment |
Working temperature/humidity: -10~50℃, 10%~90% (no condensation)
Storage temperature/humidity: -20~70℃, 5%-95% (no condensation) |
|
Mechanical structure |
Housing: Metal housing, IP20 protection grade
Installation: 19-inch 1U rack mount |
|
Certification |
CE, FCC, RoHS |
