Standards and protocols
|
10Base-T, following IEEE 802.3
100Base-TX, following IEEE 802.3u
1000Base-T, following IEEE 802.3ab
1000Base X, following IEEE 802.3z
10GBase X, following IEEE802.3ae
Spanning tree, following IEEE 802.1D
Fast spanning tree, following IEEE 802.1w
Multiple spanning trees, following IEEE 802.1s
Service, following IEEE 802.1p
VLAN, following IEEE 802.1Q
Flow control, following IEEE 802.3x
Asymmetric flow control, following IEEE 802.3z
Link aggregation, following IEEE 802.3ad
|
|
MAC exchange
|
Supports static configuration and dynamic learning of MAC addresses
Support for viewing and clearing MAC addresses
MAC address aging time configurable
Support MAC address learning quantity limit
Support MAC address filtering function
Support IEEE 802.1AE MacSec security control
|
| VLAN |
Supports 4K VLAN table entries
Support GVRP
Support for QinQ function
Support for Private VLAN
Support for voice valn
|
|
Ring network protection
|
Supports 802.1D (STP), 802.1W (RSTP), 802.1S (MSTP)
Supports BPDU protection, root protection, and loop protection
Support EAPS Ethernet link automatic protection protocol
Supports ERPS Ethernet ring network protection protocol
|
| Multicast |
Supports IGMP v1/v2/v3
Supports IGMP Snooping
Supports IGMP Fast Leave
Support multicast group policies and limit the number of
multicast groups
Support multicast traffic replication across VLANs |
|
IP Routing
|
Supports ipv4/ipv6 dual stack protocol
Supports static routing
Supports RIP v1/v2, OSPF, IS-IS, and BEIGRP dynamic routing
Support VRRP virtual routing
|
|
IPv6
|
Supports ICMPv6, DHCPv6, ACLv6, IPv6 Telnet
Supports IPv6 neighbor discovery
Support for Path MTU discovery
Supports MLD v1/v2
Support for MLD Snooping
|
|
DHCP
|
Support for DHCP Server
Supports DHCP Relay
Supports DHCP Client
Supports DHCP Snooping
|
| ACL |
Supports second, third, and fourth layer ACLs
Supports IPv4 and IPv6 ACLs
Support VLAN ACL
|
|
QoS
|
Support traffic classification based on L2/L3/L4 protocol header fields
Support CAR traffic restriction
Support 802.1P/DSCP priority re labeling
Support queue scheduling methods such as SP, WRR, SP+WRR, etc
Supports congestion avoidance mechanisms such as Tail-Drop and WRED
Support traffic supervision and traffic shaping
|
|
Virtualization
|
Support for VSS virtualization
|
|
Safety characteristics
|
Support ACL flow recognition and filtering security mechanism based on L2/L3/L4
Support anti DDoS attacks, TCP SYN Flood attacks, UDP Flood attacks, etc
Supports suppression of multicast, broadcast, and unknown unicast messages
Supports port isolation
Supports port security, IP+MAC+port binding
Supports DHCP sourcing, DHCP option82
Supports IEEE 802.1x authentication
Support for Radius, Tacacs+certification
Support for command line hierarchical protection
|
| Reliability |
Support static/LACP link aggregation
Supports UDLD one-way link detection
Supports Ethernet OAM
Support uninterrupted system upgrade for ISSU business
|
|
Management
maintenance
|
Support for Console, Telnet, SSH 2.0
Support ZTP zero contact configuration activation (Zero Touch Provisioning)
Support browser based WEB management
Supports SNMP v1/v2/v3
Support TFTP file upload and download management
Support for RMON event history
|
|
Green and energy-saving
|
Supports IEEE 802.3az Green Energy Efficient Ethernet
|
|
Power Supply
|
100~240VAC 50Hz 10%
|
|
Work Environment
|
Working temperature/humidity: -10~50 ℃, 10%~90% (without
condensation)
Storage temperature/humidity: -20~70 ℃, 5% -95% (without
condensation) |
|
Mechanical structure
|
Shell: Metal shell, IP20 protection level
Installation: 19 inch 1U rack mounted
|
