Standards and protocols |
10Base-T, following IEEE 802.3
100Base-TX, following IEEE 802.3u
1000Base-T, following IEEE 802.3ab
1000Base X, following IEEE 802.3z
10GBase X, following IEEE802.3ae
Spanning tree, following IEEE 802.1D
Fast spanning tree, following IEEE 802.1w
Multiple spanning trees, following IEEE 802.1s
Service, following IEEE 802.1p
VLAN, following IEEE 802.1Q
Flow control, following IEEE 802.3x
Asymmetric flow control, following IEEE 802.3z
Link aggregation, following IEEE 802.3ad |
|
MAC Switching |
Supports static configuration and dynamic learning of MAC addresses
Support for viewing and clearing MAC addresses
MAC address aging time configurable
Support MAC address learning quantity limit
Support MAC address filtering function
Support IEEE 802.1AE MacSec security control |
|
VLAN |
Support 4K VLAN entries
Support GVRP
Support QinQ function
Support Private VLAN
Support voice valn |
|
Ring network protection |
Supports 802.1D (STP), 802.1W (RSTP), 802.1S (MSTP)
Supports BPDU protection, root protection, and loop protection
Support EAPS Ethernet link automatic protection protocol
Supports ERPS Ethernet ring network protection protocol |
|
Multicast |
Supports IGMP v1/v2/v3
Supports IGMP Snooping
Supports IGMP Fast Leave
Support multicast group policies and limit the number of multicast groups
Support multicast traffic replication across VLANs |
|
IP Routing |
Support ipv4/ipv6 dual stack protocol
Support static routing
Support RIP v1/v2, OSPF dynamic routing
Support VRRP virtual routing |
|
IPv6 |
Support ICMPv6, DHCPv6, ACLv6, IPv6 Telnet
Support IPv6 neighbor discovery
Support Path MTU discovery
Support MLD v1/v2
Support MLD Snooping |
|
DHCP |
Support DHCP Server
Support DHCP Relay
Support DHCP Client
Support DHCP Snooping |
|
ACL |
Support Layer 2, Layer 3, and Layer 4 ACL
Support IPv4 and IPv6 ACL
Support VLAN ACL |
|
QoS |
Support traffic classification based on L2/L3/L4 protocol header fields
Support CAR traffic restriction
Support 802.1P/DSCP priority re labeling
Support queue scheduling methods such as SP, WRR, SP+WRR, etc
Supports congestion avoidance mechanisms such as Tail-Drop and WRED
Support traffic supervision and traffic shaping |
|
Virtualization |
Support for VSS virtualization |
|
Safety Features |
Support ACL flow recognition and filtering security mechanism based on L2/L3/L4
Support anti DDoS attacks, TCP SYN Flood attacks, UDP Flood attacks, etc
Supports suppression of multicast, broadcast, and unknown unicast messages
Supports port isolation
Supports port security, IP+MAC+port binding
Supports DHCP sourcing, DHCP option82
Supports IEEE 802.1x authentication
Support for Radius, Tacacs+certification
Support for command line hierarchical protection |
|
reliability |
Support static/LACP link aggregation
Supports UDLD one-way link detection
Supports Ethernet OAM
Support uninterrupted system upgrade for ISSU business |
|
Management and maintenance |
Support for Console, Telnet, SSH 2.0
Support ZTP zero contact configuration activation (Zero Touch Provisioning)
Support browser based WEB management
Supports SNMP v1/v2/v3
Support TFTP file upload and download management
Support for RMON event history |
|
Green and Energy Saving |
Support IEEE 802.3az Green Energy Efficient Ethernet |
|
power supply |
100~240VAC, 50Hz±10% |
|
Work Environment |
Working temperature/humidity: -10~50℃, 10%~90% (without condensation)
Storage temperature/humidity: -20~70℃, 5%-95% (without condensation) |
|
Mechanical structure |
Shell: Metal shell, IP20 protection level
Installation: 19 inch 1U rack mounted |
|
Certification |
CE, FCC, RoHS |
