System |
|
CPU |
CPU Model |
Intel® Core™ i7-1255U |
Intel® Core™ i5-1235U |
Intel® Core™ i3-1215U |
|
Graphic |
Intel® Iris® Xe Graphics, Up to 96 EUs,1.25Ghz |
Intel® Iris® Xe Graphics, Up to 80 EUs,1.2Ghz |
Intel® UHD Graphics, up to 64 EUs, 1.1Ghz |
|
TDP |
15W |
|
RAM |
1* non-ECC SO-DIMM Socket, support DDR4-3200 MHz, up to 32GB |
|
Storage |
M.2 |
1* M.2 (NGFF) 2280 M-key Slot (support PCIex4 Gen 4 NVMe) |
|
Supported OS |
Win 10; Win 10 IoT, Linux, Ubuntu, Debian, Kali, CentOS, etc. |
|
I/O Interface |
COM |
2*RS232 (COM1/2, Wafer, Full lanes);
3*RS232/TTL (COM3/4/5, Wafer, 3 lanes);
1 * RS232/RS485/TTL (COM6, Wafer, 3 lanes) |
|
Ethernet |
2* Intel® GbE LAN (10/100/1000 Mbps, RJ45) |
|
USB |
6* USB3.0 TYPE-A |
|
Video |
1* HDMI, Support 4096*2160@30Hz;
1* DP++, Support 4096*2304@60Hz |
|
Audio |
Realtek Audio HAD Codec, 1*Line-Out + MIC 2in1, 1*Amplifer Wafer, 3-W (per channel) into a 4-Ω Loads |
|
SIM |
1*SIM Card wafer |
|
Power Supply |
1 * DC 12V/24V Power Input Φ2.5mm Thread Jack |
|
Other |
1* 8-bit GPIO wafer (optional) |
|
Expansion |
1 * M.2 Key-E Slot (PCIE+USB2.0, Default PCIE, Support WIFI, 2230)
1 * M.2 Key-B Slot (PCIE + USB3.0 + USB2.0, Support 5G/4G, 2242/3052) |
|
Operating Temperature |
Non-Touch: 0~50°C; Capacitive: -20~60°C; (w/ 0.7m/s Airflow) |
|
Storage Temperature |
Non-Touch: 0 ~ 50°C; Capacitive: -20 ~ 60°C |
|
Relative Humidity |
40 °C @ 95%, Non-Condensing |
|
Dimensions |
387*255.5*94.2 mm |
|
Net Weight |
2.0 KG |
|
Mounting |
Panel mount kit (VESA mount kits optional) |
