SPECIFICATION |
|
|
OUTPUT |
|
|
Model |
NES-200-5 |
NES-200-12 |
NES-200-15 |
NES-200-24 |
NES-200-48 |
NES-200-50 |
|
DC Voltage |
5V |
12V |
15V |
24V |
48V |
50v |
|
Rated Current |
40A |
17A |
14A |
8.8A |
4.4A |
4A |
|
Current Range |
0~40A |
0~17A |
0~14A |
0~8.8A |
0~4.4A |
0-4A |
|
Rated Power |
200W |
198W |
196W |
194W |
192.5W |
190W |
|
Ripple&Noise |
80mVp-p |
120mVp-p |
120mVp-p |
120mVp-p |
200mVp-p |
200mVp-p |
|
Voltage Adj. Range |
4.75~5.5V |
11.4 ~ 13.5V |
14.25 ~ 16.5V |
22.8 ~ 27.6V |
45.6 ~ 52.8V |
45~55V |
|
Voltage Tolerance |
±2.0% |
±1.0% |
±1.0% |
±1.0% |
±1.0% |
±1.0% |
|
Line Regulation |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
|
Load Regulation |
±1.0% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
|
Setup,Rise Time |
800ms, 20ms/230VAC 1200ms, 30ms/115VAC at full load |
|
Hold Up Time |
24ms/230VAC 20ms/115VAC at full load |
|
INPUT |
|
|
Voltage Range |
90 ~ 132VAC / 180 ~ 264VAC selected by switch 254 ~ 373VDC |
|
Frequency Range |
47 ~ 63Hz |
|
Efficiency |
78% |
83% |
83% |
86% |
86% |
86% |
|
AC Current |
3A/115VAC 2A/230VAC |
|
Inrush Current |
Cold Start 45A/230VAC |
|
Leakage Current |
<2mA / 240VAC |
|
PROTECTION |
|
|
Over Load |
110 ~ 150% rated output power |
|
Protection type: Hiccup mode, recovers automatically after fault condition is removed |
|
Over Voltage |
3.8 ~ 4.65V |
5.75~6.75V |
8.6 ~ 10.1V |
10.4 ~ 12.2V |
13.8~16.2V |
17.25~20.25V |
27.6~32.4V |
55.2~64.8V |
63.2~74.2V |
|
Protection type: Hiccup mode, recovers automatically after fault condition is removed |
|
ENVIRONMENT |
|
|
Working Temp. |
-20 ~ +60℃ (Refer to output load derating curve) |
|
Working Humidity |
20 ~ 90% RH non-condensing |
|
StorageTemp., Humidity |
-40 ~ +85℃, 10 ~ 95% RH |
|
Temp. Coefficient |
±0.03%/℃ (0 ~ 50℃) |
|
Vibration |
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes |
|
SAFETY &EMC |
|
|
Safety Standards |
UL60950-1, CB(IEC60950-1),CCC GB4943 approved |
|
Withstand Voltage |
I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC |
|
Isolation Resistance |
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃ / 70% RH |
|
EMI Conduction & Radiation |
Compliance to EN55022 (CISPR22) Class B,GB9254 CLASS B |
|
Harmonic Current |
Compliance to EN61000-3-2,-3,GB17625.1 |
|
EMC Immunity |
Compliance to EN61000-4-2, 3, 4, 5, 6, 8,11, ENV50204, EN55024, EN61000-6-1, heavy industry level, criteria A |
|
OTHERS |
|
|
Dimension |
215*115*50mm (L*W*H) |
|
Weight |
0.73Kg |
|
Packing |
20pcs/carton |
|
NOTE |
|
|
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12” twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance: includes set up tolerance, line regulation and load regulation.
4. Line regulation is measured from low line to high line at rated load.
5. Load regulation is measured from 0% to 100% rated load.
6. The power supply is considered a component which will be installed into final equipment. The final equipment must be re-confirmed that it still meetsEMC directives.
7. Length of set up time is measured at cold first start. Turning ON/OFF the power supply very quickly may lead to increase of the set up time. |
