Phần mềm giám sát và điều khiển thiết bị IoT ICP DAS IoTstar Dashboard Service

Introduction

IoTstar Dashboard Service is an optional software package for IoTstar that provides users the Dashboard editor and a variety of Widget components. Based on the functions the IoTstar Dashboard Service provides, users can setup the Dashboard pages to review the real-time sensor data (or Power data) from the Sensor and Power Meter connected to WISE/PMC/PMD controllers, and it can also change the values of the DO/AO output channels of the Sensor (or power meters) connected to WISE/PMC/PMD controllers immediately.

Through the IoTstar Dashboard Service, users can quickly set up the Dashboard pages required to review the real-time sensor data (or Power data) and interact with the Sensors (and power meters) connected to WISE/PMC/PMD controllers.

Examples of Dashboard provided by IoTstar Dashboard Service:

Example of Air quality monitoring (Using Line Chart, Gauge, Plot Bar, Value Table, Value Label Overlay widgets).

Example of Power monitoring example (Using Line Chart, Value, Value Output and Rich Content widgets).

Example of Environmental monitoring (Using Line Chart, Value, Value Output, Map and Video Event List widgets).

Features

  • Provide Dashboard editor for user to edit a specific Dashboard pages flexibly.
  • Provide a variety of built-in Widgets to display the sensor data (or power data) in different formats.
  • Display the sensor data (or power data) in real-time, and the status of output channels also can be changed.
  • Support "Dark Mode" to turn the browser to dark for better visibility during night time.
  • Receive on-site snapshots or video files sent by the controller. User can browse and review the snapshots or video files received by IoTstar (For the sending of on-site snapshots or video files, please use WISE with iCAM IP camera).
  • Provide Rich Content Widget (WYSIWYG editor), and allow user to edit the content of the Widget by himself (Such as import HTML code, text, Webpage, image, video file, etc.).

Download

Datasheet

Documents

Ordering Information

IoTstar Dashboard Service Software Package

Software Package Name Description
IoTstar Dashboard Service-RC050  IoTstar Dashboard Service (Used with IoTstar-RC050)
IoTstar Dashboard Service-RC200  IoTstar Dashboard Service (Used with IoTstar-RC200)
IoTstar Dashboard Service-RC500  IoTstar Dashboard Service (Used with IoTstar-RC500)
