Introduction

IoTstar is a software developed by ICP DAS for WISE/PMC/PMD controllers in a variety of Industrial IoT applications. IoTstar can be installed on a general PC platform and works as a Private IoT Cloud system, or on the VM (Virtual Machine) platform of Microsoft Azure, IBM Bluemix, Google Cloud or Amazon AWS, etc. and works as a Public IoT Cloud system.
Using IoTstar to build the IoT Cloud system, it can provide the following services:

During the IoT Cloud system development, there is no-programming-required, and the system setting can be completed only through the web interface operation. In additon, through the SQL command, IoTstar can be quickly integrated with the Cloud platforms, data analysis tools (Power BI, Google Data Studio or SCADA system etc.) to help users quickly build the “IoT + Big Data” Cloud application and significantly reduce the time and cost of building the “IoT + Big Data” Cloud application.

System Architecture

Features

Flexible installation environment supported to quickly set up IoT Cloud system

According to the needs of the field site, the installation environment can be flexibly selected.

IoTstar can be installed on the VM (Virtual Machine) platform of the Public Cloud platform such as: Microsoft Azure, IBM Bluemix, Google Cloud or Amazon AWS to implement the Public IoT Cloud system on WISE/PMC/PMD controllers. It can reduce the loading for maintaining the IoT Cloud operating environment.

If the user concerns about the environment of the system operation or data storage, the IoTstar can also be installed on a private Windows PC (Windows 7/8/10, Windows Server) to implement the Private IoT Cloud solutions on the WISE/PMC/PMD controllers, and then the user can manage the environment by himself.

No more programming! Using Browser to set up the IoT Cloud system

Only by a few clicks on Web page of IoTstar and WISE/PMC/PMD controller to complete the setting of IoT Cloud system.

Controller Remote Access/Maintenance Service

With IoTstar, users do not need to worry about the network environment of the WISE/PMC/PMD controller, regardless of whether the controller uses the static IP, dynamic IP, virtual IP or physical IP, user can perform the status monitoring, system setting adjusting, and update the firmware of the controllers through the web interface provided by IoTstar. It can reduce the time and cost of personnel travel due to performing the maintenance operations of controllers.

Sensor Data Collection Service

Sensor data collection and import the data into the database at the cloud

With IoTstar, the Sensor Data Service can be performed to collect the Historical and Real-Time sensor data (and/or Power data) from the WISE/PMC/PMD controllers, and import the data to the Database in the Cloud. The users can quickly setup the Data Lake for the IoT and Big Data applications. The users can also modify the data in the database to change the status of the DO/AO channel of the sensor connected to controllers through the SQL command.
Please note: The Service support the mechanism of " Historical Sensor data automatically send back (to IoTstar) & recovery when disconnected network is resumed.”

Support SQL interface to speed up the integration of OT and IT systems

With the support of SQL command interface, the sensor data stored by IoTstar can be connected easily with the third-party data analysis tools (such as: Power BI, Google Data Studio, SCADA system), and ERP/MES systems. It can assist user to integrate the OT(Operational Technology) and IT(Information Technology) systems quickly and seamlessly, so that comprehensive and complete information regarding system operations can be collected with ease.

Sensor Data Recovery Mechanism

For general data collection, the sensor data will be sent to the control center and imported into the Database at cloud. But when the network experience a disconnection, the data transmitted during the disconnection period will be lost. "IoTstar (with WISE/PMC/PMD)" supports the Sensor Data Recovery Mechanism. When experiences network disconnection, all data will be stored in the SD cards in WISE/PMC/PMD. And when the network return to normal status, the data stored in SD card will be re-sent to IoTstar, and imported into Database to ensure the integrity of historical data.

Sensor Data Visualization Service

With the built-in standard web page of IoTstar, user can directly query and review the real-time or historical sensor data (and/or Power data) collected from the WISE/PMC/PMD controllers.

IoTstar also provides IoTstar Dashboard Service package. Through the Dashboard editor and a variety of Widget components provided by IoTstar, user can quickly setup the Dashboard page for the Real-Time sensor data (and Power data) collected from the WISE/PMC/PMD controllers according to their needs to review the operation status of the application system in real time.

Bot Service on Controller by using Mobile Device

IoTstar provides IoTstar Bot Service package for two-way message interactions between the WISE/PMC/PMD controller managed by IoTstar and LINE chat rooms. Users can query the real-time sensor data (and/or Power data) collected from the WISE/PMC/PMD controllers and be able to change the value of DO/AO output channels anytime and anywhere by LINE App. In addition, with the ICP DAS iCAM IP Camera, it can also receive the video recording events on the application site, so that the users can review the operating status of the equipment through their mobile phones even they are not close by.

Why IoTstar?

By using "IoTstar + WISE/PMC/PMD" solution, the users can quickly build the IoT cloud system to perform the remote maintenance on machine/Facility, as well as the remote monitoring of the environment. The "IoTstar + WISE/PMC/PMD" solution features the following benefits:

Application

Monitoring and maintenance of devices in a factory

Due to the trend of Industry 4.0 in recent years, factories in all fields start to introduce the concept of "Smart Factory" into the factories, and expect to receive significant increase in production capacity. However, to optimize the production capacity, two key requirements must be met: "Collect the information of devices in factory " and "Real-time monitoring and adjusting of the settings of the devices in the factory".

ICP DAS "IoTstar with WISE/PMC" solution meets two key requirements stated above therefore is perfect for use to achieve the goal of production capacity optimization. It brings the following benefits:

Collect the information of devices in the factory

• From the collection of operation information of devices to the import of the information into the Database, there is no need to write program during the whole process. The settings can be completed by a few clicks on a general Browser.
• Quickly integrate OT and IT systems via the SQL command interface to provide comprehensive and complete operation information of the devices.
• Analyze the sensor data from the devices, and take the corresponding action in advance to ensure the stable operation of the devices.

Real-time monitoring and adjusting the settings of the devices in the factory

• Use IoTstar Dashboard Service and IoTstar Bot Service to query and review the operating status of the devices in real time.
• IoTstar Remote Access Service provide the status monitoring, system setting adjustment and firmware update for the devices (WISE/PMC controller). It can reduce the time and cost of personnel travel due to performing the maintenance operations of the equipment.

Environment Monitoring

ICP DAS "IoTstar with WISE/PMC" solution features the following benefits and is perfect for use in an Environment monitoring system:

• From the collection of sensor data of the Environment monitoring to the import of the data into the database, there is no need to write program during the whole process. The settings can be completed by a few clicks on a general Browser.
• Quickly integrate OT and IT systems via the SQL command interface to provide comprehensive and complete environmental monitoring information.
• Analyze sensor data from the Environment monitoring system, and take the corresponding action in advance to prevent the "environmental pollution".
• Use IoTstar Dashboard Service and IoTstar Bot Service to query and review the status of environmental monitoring system in real time.
• IoTstar Remote Access Service provide the status monitoring, system setting adjustment and firmware update for the environmental monitoring facility (WISE/PMC controller). It can reduce the time and cost of personnel travel due to performing the maintenance operations of the facility.

Features

• IoT Cloud Management Software
• No more programming! Using Browsers to perform Remote Maintenance on WISE/PMC/PMD controllers, and import the I/O channel data (and Power data) from WISE/PMC/PMD controllers into the Database.
• Can be installed on the VM (Virtual Machine) of the Public Cloud platform such as: Microsoft Azure, IBM Bluemix or Amazon AWS to implement the Public IoT Cloud solutions on the WISE/PMC/PMD controllers.
• Can be installed on Windows system (Windows 7/8/10, Windows Server) to implement the Private IoT Cloud solutions on the WISE/PMC/PMD controllers.
• Enables the remote maintenance and firmware update on the WISE/PMC/PMD controllers via user-friendly and intuitive Web page interface.
• Collect the Historical and Real-Time sensor data (and Power data) from the WISE/PMC/PMD controllers, and import them into the Database. User can modify the database data to change the status of the DO/AO channel of the sensor connected to WISE/PMC/PMD through the SQL command. Please note: IoTstar currently support MS SQL.
• By Database interface, it is easy to integrate with SCADA, Data Analysis tools (Microsoft Power BI, Google Data Studio) or the Service of Cloud platform to retrieve the sensor data (and Power data) directly from the Database for Big Data analysis.
• User can review the sensor data (and Power data) directly by the built-in IoTstar Web page interface.
• The users can quickly setup the Data pool for their IoT system by receiving and importing the sensor data into the Database through the IoTstar. User can analyze the sensor data with analysis tool, the status can be known, and the necessary actions can be taken in advance to avoid possible damage.
