Items |
Description |
|
Power Supply |
DC: 9~36V,
2-pin terminal block connector, 5.08mm-2P, reverse polarity protection, surge protection
5.5*2.1 DC jack connector |
|
Working Current |
Average: 300mA@12V, max: 900mA @12V |
|
Serial port |
|
No. |
1 x RS485, 3-pin terminal block connector, 3.81mm-3P
1 x RS232，DB9 male |
|
Baud rates |
RS232: 1200/2400/4800/9600/19200/38400/57600/115200/230400
RS485: 1200/2400/4800/9600/19200/38400/57600/115200/230400 |
|
Data bits |
7, 8 |
|
Stop bits |
1, 2 |
|
Parity |
NONE, ODD, EVEN |
|
Flow Control |
RS232: Hardware flow control
RS485: 485 conflict prevention |
|
Packaging Interval |
Range: 0 ~ 1000ms, default: 0ms |
|
Packaging Length |
Range: 5 ~ 1460 bytes, default: 1000 bytes |
|
Ethernet Ports |
|
No. |
2 x Ethernet ports: 1 x WAN/LAN(configurable), 1 x LAN |
|
Interface |
RJ45, 10/100 Mbps, compliance with IEEE 802.3, supports auto MDI/MDIX, 1.5KV network isolation transformer protection |
|
Wi-Fi |
|
Standards & Frequency |
IEEE 802.11b/g/n/ac, 2.4GHz & 5.8G |
|
Working Mode |
AP/STA/AP+STA/Bridge |
|
Data speed |
867Mbps(5.8GHz) & 300Mbps(2.4GHz) |
|
MU-MIMO |
2 x 2 |
|
Modulation system |
DSSS(DBPSK.DOPSK,CCK) |
|
OFDM(BPSK,QPSK,16-QAM,64-QAM,125-QAM,256-QAM) |
|
Covering distance |
2.4G: Coverage radius up to 400 meters
5.8G: Coverage radius up to 200 meters |
|
Wi-Fi Users |
16 |
|
Antenna |
2 x 5 dBi rod antenna |
|
Antenna Connector |
2 x SMA-female |
|
Physical Property |
|
Casing material |
Metal shell, IP30 protection |
|
Dimensions |
110.5*105*26mm(L*W*H,antenna pedestal,terminal block are not included) |
|
Installation |
Wall munting, desktop placement |
|
EMC |
Surge protection: level 3, IEC61000
ESD protection: level 3, IEC61000
EFT protection: level 3, IEC61000 |
|
Operating temperature |
-25℃～+75℃ |
|
Storage temperature |
-40℃～+125℃ |
|
Operating humidity |
5% ~ 95% RH, non-condensing |
|
Storage humidity |
1% ~ 95% RH, non-condensing |
|
Software Function |
|
Network protocols |
TCP, UDP, HTTP, TLS, MQTT, ARP, DHCP, ICMP, PPPoE, IPv4, DNS, SNMP, NTP, |
|
Modbus Gateway |
Modbus RTU/TCP protocol conversion,
Modbus multi-host polling |
|
IP |
DHCP/StaticIP |
|
MQTT |
Standard MQTT protocol, 16 subscription topics and 16 publish topics |
|
Registration packet |
√ |
|
Heartbeat packet |
√ |
|
IOT PLATFORMS |
AWS IOT, Alibaba cloud, PUSR cloud |
|
User Configuring |
Web console(HTTP), AT command |
|
Others |
|
Reload |
Pinhole reset button, press and hold for 3~15 to reset to factory settings |
|
Indicators |
1 x RS485, 1 x RS232, 1x WLAN, 1 x RUN, 1 x PWR |
|
Ground protection |
Screw |
|
APPROVALS |
|
Regulatory |
CE/RED*, RoHS*, WEEE*, FCC* |
