Ram công nghiệp DDR3 SO-DIMM 1600MHz 4GB PC3-12800 Cervoz CIR-S3SUSPM1604G
DDR3 SO-DIMM is a compact industrial standards memory module that fits neatly into any embedded, surveillance and automation setup. The modules comply with all relevant JEDEC standards and are available in 1GB, 2GB, 4GB, and 8GB capacities and with data transfer rates of 1066MT/s, 1333MT/s, 1600MT/s, and 1866MT/s.
The CIR-S3SUSPM1604G is 512M words X 64 bits, 1 rank. Unbuffered Small Outline Dual In-Line Memory Module (SO-DIMM). DDR3 SDRAMs in Fine Ball Grid Array(FBGA) packages on a 204pin glass-epoxy substrate. Provide a high performance 8 byte interface in 67.60mm width form factor of industry standard. It is suitable for easy interchange and addition.
Features
- Data rate:1600MHz
- 204pin,Small outline dual in-line memory module(SO-DIMM)
- Power supply: VDD= 1.5V (1.425V to 1.575V) & VDD= 1.35V (1.283V to 1.45V)
- Interface: SSTL_15
- CAS (READ) latency (CL): 6, 7, 8, 9, 10, 11
- POSTED CAS ADDITIVE latency (AL)
- Fully differential clock inputs (CK, /CK) operation
- Differential Data Strobe (DQS, /DQS)
- DM masks write data-in at the both rising and falling edges of the data strobe
- BL switch on the fly
- 8banks
- 8K refresh cycles /64ms
- Dynamic On Die Termination supported
- Asynchronous RESET pin supported
- ZQ calibration supported
- TDQS (Termination Data Strobe) supported (x8 only)
- Write Levelization supported
- Refresh: Auto-Refresh, Self-Refresh
- 8 bit pre-fetch
- Lead-Free Products are RoHS compliant
- TCASE of 0°C to 95°C (Components)
- —64ms, 8,192 cycle refresh at 0°C to 85°C
- —32ms at 85°C to 95°C
Speed Grade
| Frequency Grade |
Data Transfer Rate |
CAS Latency Support |
CL-tRCD-tRP |
| CL6 |
CL7 |
CL8 |
CL9 |
CL10 |
CL11 |
| DDR3-1600 |
PC3-12800 |
800 |
1066 |
1066 |
1333 |
1333 |
1600 |
11-11-11 |
| Model No. |
IC Organization |
Speed (MT/s) |
Density |
Voltage |
Download |
|
CIR-S3SUSPM1604G |
512Mx8 |
1600 |
4GB |
1.5V/1.35V |
0.38 MB |
