Phần mềm SCADA UltimateAccess Web Runtime Unlimited Tags Cimon UA02-FULL/RS

Chia sẻ:
Mã sản phẩm: UA02-FULL/RS
Thương hiệu: Cimon
Tình trạng:

Full tag HTML 5 based Web Server + Runtime

Liên hệ
Mô tả

Phần mềm SCADA UltimateAccess Web Runtime Unlimited Tags Cimon UA02-FULL/RS

Phần mềm Scada Cimon là một phần mềm được phát triển bởi hãng CIMON của Hàn Quốc. Phần mềm Scada Cimon được thiết kế với cấu trúc mở, có giao diện dễ sử dụng, hỗ trợ thư viện hình ảnh đa dạng, hỗ trợ ngôn ngữ Visual Basic, ODBC, với SQL để dễ dàng kết nối với bất kỳ cơ sở dữ liệu nào. Với giao diện đơn giản, khả năng tương thích giao tiếp với nhiều thiết bị công nghiệp giúp người dùng dễ dàng xây dựng một hệ thống tối ưu, ổn định và tiết kiệm.

Tính năng

1. Web Server

Through HTML5-based web browsers, users can monitor and control their system(s) at any time, from anywhere on PC, tablet, or smartphone. For advanced security, SSL and HTTPS are supported by default.

2. 3D Objects

Support multi-axis rotation of 3DB, OBJ, STL, and GLB fle types. This would allow a user to easily identify a failure point by the color change, rotation, or by zooming in and out

3. CIMON Historian Database

Integrated PostgreSQL and TimescaleDB can collect and manage large time-series data for energy management, maintenance, process optimization, and other applications

4. Improved Data Analysis

Historical trend types such as YT and XY are supported to analyze data intuitively. A maximum of 16 pens and 100,000 data points per pen may be displayed on a single trend for a comprehensive and accurate information display.

5. IEC 61850 Edition 2

IEC 61850 protocol with direct addressing and Manufacturing Message Specifcation (MMS) for intelligent electronic devices at electrical substations is available.

6. IP Camera

Integrate Internet Protocol (IP) cameras seamlessly via IP address confguration while monitoring the feed with Real-Time Streaming Protocol (RTSP)

7. Licensing Models

Dongle-based license and tag-based software. Every designer license is coupled with a runtime license. Typically end users will exclusively use the runtime-only license. Many tiers of tag count exist as well, up to unlimited.

8. Audit Trail

Tools are provided to meet the audit trail and electronic data records requirements of the FDA 21 CFR Part 11 compliance. Prevent unauthorized access to all objects and the project itself while maintaining a record of operator actions

9. Autonomous Behavior

Take advantage of the autonomous scripting feature provided in the SCADA package that utilizes Visual Basic syntax. The help fle is full of complete examples to assist with the learning curve as well.

10. Page Recorder

Track every point of interest on a page when an alarm event occurs. Recordings will be stored to the SCADA PC for playback and troubleshooting purposes

11. Reporting

Generate custom Excel or Word documents with the data analysis. Ready to print and compute at anytime.

12. Vast Communication Drivers

Equipped with over 200 native protocols, such as EtherNet/IP, OPC UA, BACnet, S7, Modbus RTU/TCP, TCP/IP, and more. Ready to communicate with industry standards

13. SVG Object Support

In addition to BMP, PNG, and GIF formats, SVG format is supported so users can preserve image quality when resizing

14. ODBC

Integrate your data into any SQL Server using UltimateAccess Web’s ODBC protocol.

15. SVG Image Library

Provides the best image quality that caters to any page size or project requirement. Choose from over 3000 provided images to expedite project creation.

16. Pictorial Charts

Give your data a different look using charts such as bar graphs, pie charts, stacked area charts, radar area charts, and many more

Thông tin đặt hàng

Development + Runtime bundle

Model Type Description
UA02-0075/RS 75 Tags HTML 5 based Web Server + Runtime
UA02-0150/RS 150 Tags HTML 5 based Web Server + Runtime
UA02-0500/RS 500 Tags HTML 5 based Web Server + Runtime
UA02-1500/RS 1500 Tags HTML 5 based Web Server + Runtime
UA02-3000/RS 3000 Tags HTML 5 based Web Server + Runtime
UA02-FULL/RS Unlimited Tags HTML 5 based Web Server + Runtime

Tài liệu

Catalog

Manual
