Module 2 cổng PoE Ethernet Modbus TCP & MQTT 16 kênh DI/DO ICP DAS PET-2254P CR

Module 2 cổng PoE Ethernet Modbus TCP & MQTT 16 kênh DI/DO ICP DAS PET-2254P CR

Features

• Built-in Web Server
• Support Modbus TCP/UDP, MQTT, and SNMP V2c Protocols
• 2-port Ethernet Switch (LAN Bypass) for Daisy-Chain Wiring
• Dual Watchdog
• I/O Pair Connection (Push and Pull)
• 16-channel programmable Universal DIO
• Provide Digital Output Maximum Load Current:
  • (P)ET-2254: 100 mA/Channel
  • (P)ET-2254P: 350 mA/Channel
• LED Display to Indicate the I/O Status

Introduction

Providing a variety of digital I/O functions, the PET-2254P module is an Ethernet I/O monitoring and control module. The module can be remotely controlled through a 10/100 M Ethernet network by using Modbus TCP/UDP protocol. Modbus has become a de facto standard communications protocol in industrial applications and is now the most commonly available means of connecting industrial electronic devices. This makes the PET-2254P module perfectly integrated with the HMI, SCADA, PLC, or other software systems.

The PET-2254P provides a 16-channel programmable universal DIO. Each I/O port can be configured as DI or DO port. The PET-2254P provides the digital output channel that can drive 350 mA load, also configurable power-on, and safe values for digital output. With 2 Ethernet ports, the PET-2254P allows a daisy chain connection which enables flexibility in locating devices; easy installation, and lower infrastructure costs. It features 8 kV ESD protection, 4 kV EFT protection, 3 kV surge, and 3000 VDC I/O isolation to enhance noise protection capabilities in industrial environments.

The module can be used to create DI to DO pair-connect through the Ethernet. After configuration, the PET-2254P module can continuously poll the status of the local DI channels and then write to the remote DO devices via the Modbus/TCP protocol.

It is equipped with a removable terminal block connector for easy and robust wiring in industrial applications and features a powerful 32-bit ARM MCU to handle efficient network trafficking.

PET-2254P module supports MQTT protocol and can act as a message publisher and subscriber. After connecting to the server MQTT Broker, the I/O status of the module can be published in the form of a topic, and can also receive messages from the same subscription topics. In communication, when the PET-2254P module is disconnected from the broker, the module has a reconnection mechanism that can automatically reconnect with the broker. In addition, there is a Keep-Alive Interval mechanism to ensure that the connection with the Broker is always maintained.

The PET-2254P supports the standard SNMP V2c specification. Through this specification, ET-2200 can transmit module information and I/O information to SNMP network management equipment or software (SNMP Network Management Software) to help administrators monitor the status of ET-2200 in real time. If the Trap function is enabled, when the module I/O status changes or reboots, it can send a message to the manager to keep track of the channel status at any time.

Applications

• Factory, Building and Home Automation Remote Maintenance.

Specifications

Download

Datasheet

Documents

Ordering Information
