Bộ đổi nguồn Din-Rail MCTT-MDR-60-5 50W, 5VDC, 10A
60W Single Output DIN Rail Power Supply MDR-60 series
Features:
Universal AC input/ full range
Protections: Short circuit/ Over load/ Over voltage
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
isolation classⅡ
LED indicator for power on
100% full load burn-in test
2 year warranty
|
SPECIFICATIONS |
|
OUTPUT |
|
|
Model |
MCTT-MDR-60-5 |
MCTT-MDR-60-12 |
MCTT-MDR-60-15 |
MCTT-MDR-60-24 |
|
DC Voltage |
5V |
12V |
15V |
24V |
|
Rated Current |
10A |
5A |
4A |
2.5A |
|
Current Range |
0-10A |
0-5A |
0-4A |
0-2.5A |
|
Rated Power |
50W |
60W |
60W |
60W |
|
Ripple & Noise |
80mVp-p |
120mVp-p |
120mVp-p |
150mVp-p |
|
Voltage Adj. Range |
-5%,+10% |
-8%,+10% |
±10% |
±10% |
|
Voltage Tolerance |
±2% |
±1% |
±1% |
±1% |
|
Setup, Rise Time |
500ms,30ms/230VAC200ms,30ms/115VAC at full load |
|
Hold Up Time |
50ms/230VAC20ms/115VAC at full load |
|
|
|
|
INPUT |
|
|
Voltage Range |
88~264VAC47~63Hz; 124~370VDC |
|
AC Current |
1.8A/115V 1A/ 230V |
|
Efficiency |
76% |
82% |
83% |
84% |
|
Inrush Current |
Cold start 18A/115V 36A/230V |
|
Leakage Current |
<1mA/240VAC |
|
|
|
|
PROTECTION |
|
|
Over Load |
105%~160% |
|
Protection type: Constant current limiting, recovers automatically after fault condition is removed |
|
Over Voltage |
115%~135% |
|
Protection type: Shut down o/p voltage, re-power on to recover |
|
|
|
|
ENVIRONMENT |
|
|
Working Temp., Humidity |
-20℃~+60℃; 20%~90%RH |
|
Storage Temp., Humidity |
-40℃~+85℃; 10%~95%RH |
|
Temp. Coefficient |
±0.03%/℃(0~50℃) |
|
Vibration |
10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes |
|
|
|
|
SAFETY |
|
|
Withstand Voltage |
I/P-O/P: 3KVAC |
|
Isolation Resistance |
I/P-O/P: 100M Ohms / 500VDC |
|
|
|
|
STANDARD |
|
|
Safety Standard |
Design refer to UL60950-1,TUV EN60950-1,EN50178 |
|
EMC Standard |
Design refer to EN55011,EN55022,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,ENV50204,EN55024,EN61000-6-2，EN61204-3 |
|
|
|
|
OTHERS |
|
|
Dimension |
100*90*40mm(L*W*H) |
|
Weight |
0.33Kg |
|
Packing |
50pcs/carton |
|
|
|
|
NOTE |
|
|
1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
2.Ripple & noise are measured at 20MHz of bandwidth by using a 12”twisted pair-wire terminated with a 0.1μ & 47μparallel capacitor.
3.Tolerance: includes set up tolerance, line regulation and load regulation.
4.The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. |
