Bộ lập trình PLC Kinco KW213-08DTX-R2 (8*DIO, 1*RS485, LoRa wireless)
Kinco KW series PLC is a kind of Small integrated PLC, wireless products for intelligent manufacturing.
KW Series PLC in the continuation of the K5, K2 series of rich functions, high performance and high reliability of the premise, the use of higher performance CPU. It also provides functions closer to users' needs, such as built-in Ethernet interface, MicroUSB, high performance high-speed input and output, compact installation, and rich extension modules. It can also meet the needs of users in various applications.
Tính năng
Thông số kỹ thuật
| Model |
Order number |
Specification |
| Power supply |
IO |
Port |
Wireless band |
Number of expansion modules |
Dimension (L*W*H) |
| KW2 |
KW203-12DT-R2 |
DC 24V |
8*DI, 4*DIO.
Include: 4 high-speed pulse inputs, 2 high-speed pulse output, max 200KHz |
1*RS485, 1*RS232, 1*CAN, 1*LoRa (wireless) |
2.4GHz |
Up to 14 |
100*84.5*25.4 mm |
| KW213 |
KW213-08DTX-R2 |
DC 24V |
8*DIO transistor |
1*RS485, 1*LoRa (wireless) |
2.4~2.5GHz |
Extension bus: not support.
Programming port: Micro USB |
100*84.5*25.4 mm |
Thông tin đặt hàng
DC24V power supply, DIO 8*DC24V, 1*RS485, 1* LoRa (wireless)
Tài liệu
Catalog
Kinco_enUserManual for K6 PLC
