PLC S7-1500 | Tổng quan SIMATIC S7-1500 Siemens – Phần 2
MFP CPU S7-1500
CPU 1518-4 PN/DP MFP
- Phù hợp với các ứng dụng đòi hỏi hiệu suất cao với ngôn ngữ lập trình cấp cao
- Tích hợp 2 cổng PN IO IRT, 1 cổng PN IO RT, 1 cổng PN (Gbit)
- Hỗ trợ giao thức Profibus DP
- Bộ nhớ chương trình 4 MB. Bộ nhớ dữ liệu: 20 MB
- Hiệu suất Bit: 1 ns
- Khả năng kết nối: 384
- Khả năng điều khiển chuyển động/vị trí: 10240
CPU 1518F-4 PN/DP MFP
- Phù hợp với các ứng dụng đòi hỏi hiệu suất cao với ngôn ngữ lập trình cấp cao
- Tích hợp 2 cổng PN IO IRT, 1 cổng PN IO RT, 1 cổng PN (Gbit)
- Hỗ trợ giao thức Profibus DP
- Bộ nhớ chương trình 6 MB. Bộ nhớ dữ liệu: 20 MB
- Hiệu suất Bit: 1 ns
- Khả năng kết nối: 384
- Khả năng điều khiển chuyển động/vị trí: 10240
Redundant / high-availability CPU S7-1500
| SIMATIC S7-1500R, CPU 1513R-1PN, central processing unit with work memory 300 KB for program and 1.5 MB for data, 1st interface: PROFINET RT With 2-port switch, SIMATIC memory card required * Special release required. Please contact your Siemens representative | 6ES7513-1RL00-0AB0 |
| SIMATIC S7-1500R, CPU 1515R-2 PN central processing unit with work memory 500 KB for program and 3 MB for data, 1st interface: PROFINET RT With 2-port switch, 2nd interface: PROFINET, SIMATIC memory card required * Special release required. Please contact your Siemens representative | 6ES7515-2RM00-0AB0 |
| SIMATIC S7-1500H, CPU 1517H System bundle consisting of: 2 x CPU 1517H-3 PN, 4 sync modules up to 10 m. 2 x sync lines 1 m Without memory card * Special release required. Please contact your Siemens representative | 6ES7500-0HP00-0AB0 |
| SIMATIC S7-1500H, CPU 1517H-3 PN, central processing unit with work memory 2 MB for program and 8 MB for data, 1st interface: PROFINET RT With 2-port switch, 2nd interface: PROFINET, 3rd/4th interface: H-SYNC, SIMATIC memory card required * Special release required. Please contact your Siemens representative | 6ES7517-3HP00-0AB0 |
CPU 1513R-1 PN
- Phù hợp với các ứng dụng trung bình
- Tích hợp 2 cổng PN IO RT
- Bộ nhớ chương trình 300 KB. Bộ nhớ dữ liệu: 1.5 MB
- Hiệu suất Bit: 80 ns
- Khả năng kết nối: 88
CPU 1515R-2 PN
- Phù hợp với các ứng dụng từ trung bình đến lớn
- Tích hợp 2 cổng PN IO RT, 1 cổng PN (Gbit)
- Bộ nhớ chương trình 500 KB. Bộ nhớ dữ liệu: 3 MB
- Hiệu suất Bit: 60 ns
- Khả năng kết nối: 108
CPU 1517H-3 PN
- Phù hợp với các ứng dụng đòi hỏi khắt khe
- Tích hợp 2 cổng PN IO RT, 1 cổng PN (Gbit)
- Bộ nhớ chương trình 2 MB. Bộ nhớ dữ liệu: 8 MB
- Hiệu suất Bit: 4 ns
- Khả năng kết nối: 160
Module nguồn S7-1500 (PS – Power supplies)
Module nguồn tiêu chuẩn
| SIMATIC PM 1507 24 V/3 A Stabilized power supply for SIMATIC S7-1500 input: 120/230 V AC, output: 24 V DC/3 A | 6EP1332-4BA00 |
| SIMATIC PM 1507 24 V/8 A Regulated power supply for SIMATIC S7-1500 input: 120/230 V AC, output: 24 V DC/8 A | 6EP1333-4BA00 |
| SIMATIC S7-1500, System power supply PS 25W 24 V DC, supplies the backplane bus of the S7-1500 with operating voltage | 6ES7505-0KA00-0AB0 |
| SIMATIC S7-1500, System power supply PS 60W 24/48/60 V DC, supplies the backplane bus of the S7-1500 with operating voltage | 6ES7505-0RA00-0AB0 |
| SIMATIC S7-1500, System power supply with buffer functionality PS 60W 24/48/60V DC HF, supplies the backplane bus of the S7-1500 with operating voltage and permits the CPU to retain RAM (data) retentively | 6ES7505-0RB00-0AB0 |
| SIMATIC S7-1500, system power supply PS 60W 120/230V AC/DC, supplies the backplane bus of S7-1500 with operating voltage | 6ES7507-0RA00-0AB0 |
SIPLUS Module nguồn
| SIPLUS S7-1500 PM 1507 24 V/3 A -40 … +70°C with conformal coating based on 6EP1332-4BA00 . STABILIZED POWER SUPPLY INPUT: 120/230 V AC OUTPUT: 24 V/3 A DC | 6AG1332-4BA00-7AA0 |
| SIPLUS S7-1500 PM 1507 24 V/8 A -40 … +70°C with conformal coating based on 6EP1333-4BA00 . STABILIZED POWER SUPPLY FOR SIMATIC S7-1500 INPUT: 120/230 V AC OUTPUT: 24 V/8 A DC | 6AG1333-4BA00-7AA0 |
| SIPLUS S7-1500 PS 1505 25W 24VD 40…+70°C start up -25°C with conformal coating based on 6ES7505-0KA00-0AB0 . SYSTEM POWER SUPPLY SUPPLIES THE OPERATING VOLTAGE THE S7-1500 VIA THE BACKPLANE B | 6AG1505-0KA00-7AB0 |
| SIPLUS S7-1500, System power supply PS 60W 24/48/60 V DC, supplies the backplane bus of the S7-1500 with operating voltage -25…+70°C with conformal coating based on 6ES7505-0RA00-0AB0 | 6AG1505-0RA00-7AB0 |
| SIPLUS S7-1500, System power supply PS 60W 120/AC 230 V DC, supplies the backplane bus of the S7-1500 with operating voltage -40…+70°C start up -25°C with conformal coating based on 6ES7507-0RA00-0AB0 | 6AG1507-0RA00-7AB0 |
Module DI/DO cho S7-1500
Module I/O hay còn được gọi là Mô-đun tín hiệu (Signal module (SM))
Module DI/DO tiêu chuẩn
| Module DI | |
| SIMATIC S7-1500 Digital input module DI 16xDC 24V HF, 16 channels in groups of 16; input delay 0.05..20 ms; Input type 3 (IEC 61131); Diagnostics, hardware interrupts: Front connector (screw terminals or push-in) to be ordered separately | 6ES7521-1BH00-0AB0 |
| SIMATIC S7-1500 Digital input module, DI 16×24 V DC BA, 16 channels in groups of 16, input delay typ. 3.2 ms, input type 3 (IEC 61131); Delivery incl. front connector Push-in | 6ES7521-1BH10-0AA0 |
| SIMATIC S7-1500, digital input module DI 16×24 V DC BA, sourcing input; 16 channels in groups of 16; Input delay 3.2 ms; Input type 3 (IEC 61131): Front connector (screw terminals or push-in) to be ordered separately | 6ES7521-1BH50-0AA0 |
| SIMATIC S7-1500, digital input module DI 32×24 V DC HF, 32 channels in groups of 16; Input delay 0.05..20 ms Input type 3 (IEC 61131); Diagnostics, hardware interrupts: Front connector (screw terminals or push-in) to be ordered separately | 6ES7521-1BL00-0AB0 |
| SIMATIC S7-1500 Digital input module, DI 32×24 V DC BA, 32 channels in groups of 16, Input delay typ. 3.2 ms, Input type 3 (IEC 61131); Delivery incl. front connector Push-in | 6ES7521-1BL10-0AA0 |
| SIMATIC S7-1500, digital input module, DI 64xDC 24V SNK/SRC BA, 64 channels in groups of 16, input delay typ. 3.2 ms, input type 3 (IEC 61131); sinking/sourcing input. 35 mm wide, cables and terminal blocks to be ordered separately as accessories | 6ES7521-1BP00-0AA0 |
| SIMATIC S7-1500, digital input module DI 16×230 V AC BA, 16 channels in groups of 4; Input delay 20 ms; Input type 1 (IEC 61131): Front connector (screw terminals or push-in) to be ordered separately | 6ES7521-1FH00-0AA0 |
| SIMATIC S7-1500, digital input module DI 16x 24…125 V UC HF, 16 channels in groups of 1; input delay 0.05..20 ms; Input type 3 (IEC 61131); Diagnostics, hardware interrupts: Front connector (screw terminals or push-in) to be ordered separately | 6ES7521-7EH00-0AB0 |
| Module DO | |
| SIMATIC S7-1500 digital output module DQ 8×24 V DC/2A HF; 8 channels in groups of 8; 8 A per group; diagnostics; substitute value: the module supports the safety-oriented shutdown of load groups up to SILCL2 acc. to EN 62061:2005 + A2:2015, and Category 3 / PL d according to EN ISO 13849-1:2015. front connector (screw terminals or push-in) to be ordered separately | 6ES7522-1BF00-0AB0 |
| SIMATIC S7-1500, digital output module DQ16x24 V DC/0.5A HF; 16 channels in groups of 8; 4 A per group; single-channel diagnostics; substitute value: the module supports the safety-oriented shutdown of load groups up to SILCL2 acc. to EN 62061:2005 + A2:2015, and Category 3 / PL d according to EN ISO 13849-1:2015. front connector (screw terminals or push-in) to be ordered separately | 6ES7522-1BH01-0AB0 |
| SIMATIC S7-1500, digital output module, DQ16x24 V DC/0.5A BA, 16 channels in groups of 8, 4 A per group; the module supports the safety-oriented shutdown of load groups up to SILCL2 acc. to EN 62061:2005 + A2:2015, and Category 3 / PL d according to EN ISO 13849-1:2015. delivery incl. front connector push-in | 6ES7522-1BH10-0AA0 |
| SIMATIC S7-1500, digital output module DQ 32×24 V DC/0.5A HF; 32 channels in groups of 8; 4 A per group; single-channel diagnostics; substitute value: the module supports the safety-oriented shutdown of load groups up to SILCL2 acc. to EN 62061:2005 + A2:2015, and Category 3 / PL d according to EN ISO 13849-1:2015. front connector (screw terminals or push-in) to be ordered separately | 6ES7522-1BL01-0AB0 |
| SIMATIC S7-1500, digital output module, DQ32x24 V DC/0.5A BA, 32 channels in groups of 8, 4 A per group; the module supports the safety-oriented shutdown of load groups up to SILCL2 acc. to EN 62061:2005 + A2:2015, and Category 3 / PL d according to EN ISO 13849-1:2015. delivery incl. front connector push-in | 6ES7522-1BL10-0AA0 |
| SIMATIC S7-1500, digital output module, DQ 64xDC 24V/0.3A BA, 64 channels in groups of 16, 2 A per group at 60 °C, sinking output, 35 mm wide, the module supports the safety-oriented shutdown of load groups up to SILCL2 acc. to EN 62061:2005 + A2:2015, and Category 3 / PL d according to EN ISO 13849-1:2015. cables and terminal blocks to be ordered separately as accessories | 6ES7522-1BP00-0AA0 |
| SIMATIC S7-1500, digital output module, DQ 64xDC 24V/0.3A SNK BA, 64 channels in groups of 16, 2 A per group at 60 °C, sourcing output, 35 mm wide cables and terminal blocks to be ordered separately as accessories | 6ES7522-1BP50-0AA0 |
| SIMATIC S7-1500, digital output module DQ16x24..48VUC/125V DC/0.5A ST; 16 channels in groups of 1; 0.5 A per group; substitute value: observe derating the module supports the safety-oriented shutdown of load groups up to SILCL2 acc. to EN 62061:2005 + A2:2015, and Category 3 / PL d according to EN ISO 13849-1:2015. front connector (screw terminals or push-in) to be ordered separately | 6ES7522-5EH00-0AB0 |
| SIMATIC S7-1500, digital output module DQ 8×230 V AC/2 A ST; TRIAC; 8 channels in groups of 1; 2 A per group; Substitute value: Front connector (screw terminals or push-in) to be ordered separately | 6ES7522-5FF00-0AB0 |
| SIMATIC S7-1500, digital output module DQ 16×230 V AC/1 A ST; TRIAC; 16 channels in groups of 2; 2 A per group; Substitute value: Front connector (screw terminals or push-in) to be ordered separately | 6ES7522-5FH00-0AB0 |
| SIMATIC S7-1500, digital output module DQ 8xAC 230V/5A ST; relay; 8 channels in groups of 1; 5 A per group; diagnostics; substitute value: switching cycle counter for integrated relay, the module supports the safety-oriented shutdown of load groups up to SILCL1 according to EN 62061:2005 + A2:2015, and Category 2 / PL c according to EN ISO 13849-1:2015. front connector (screw terminals or push-in) to be ordered separately | 6ES7522-5HF00-0AB0 |
| SIMATIC S7-1500, digital output module DQ 16x 230 V AC/2A ST; Relay 16 channels in groups of 2; 4 A per group; switching cycle counter for integrated relay, diagnostics; substitute value: the module supports the safety-oriented shutdown of load groups up to SILCL1 according to EN 62061:2005 + A2:2015, and Category 2 / PL c according to EN ISO 13849-1:2015. front connector (screw terminals or push-in) to be ordered separately | 6ES7522-5HH00-0AB0 |
| Module DI/DO | |
| SIMATIC S7-1500 digital input/output module, DI16x 24VDC BA, 16 channels in groups of 16, input delay typ. 3.2 ms input type 3 (IEC 61131), DQ16X24 V DC/0.5A BA; 16 channels in groups of 8; 4 A per group; the module supports the safety-oriented shutdown of load groups up to SILCL1 according to EN 62061:2005 + A2:2015, and Category 2 / PL c according to EN ISO 13849-1:2015. delivery incl. front connector push-in | 6ES7523-1BL00-0AA0 |
| SIMATIC S7-1500 digital input/output module, DI 32x24VDC BA SNK / SRC, 32 channels in groups of 16, input delay typ. 3.2 ms input type 3 (IEC 61131), sinking/sourcing input, DQ 32XDC 24V/0.3A SNK BA; 32 channels in groups of 16; 2 A per group at 60 °C; sourcing output; 35 mm wide; cables and terminal blocks to be ordered separately as accessories | 6ES7523-1BP50-0AA0 |
SIPLUS Module DI/DO
| Module DI | |
| SIPLUS S7-1500 DI 16×24 V DC HF -40…+70°C with conformal coating based on 6ES7521-1BH00-0AB0 . Digital input module 16 channels in groups of 16; Input delay 0.05..20ms Input type 3 (IEC 61131); diagnostics; hardware interrupts | 6AG1521-1BH00-7AB0 |
| SIPLUS S7-1500 DI 16×24 V DC SRC -40…+70°C with conformal coating based on 6ES7521-1BH50-0AA0 . Digital input module DI 16×24 V DC, source-input; 16 channels in groups of 16; Input delay 3.2 ms; Input type 3 (IEC 61131) | 6AG1521-1BH50-7AA0 |
| SIPLUS S7-1500 DI 32X24VDC HF -40 … +70°C with conformal coating based on. Digital input module DI 32x24V DC HF, 32 channels in groups of 16 Input delay 0.05..20 ms Input type 3 (IEC 61131) diagnostics Hardware interrupts | 6AG1521-1BL00-7AB0 |
| SIPLUS S7-1500 DI 16x230V AC BA -40…+70°C with conformal coating based on 6ES7521-1FH00-0AA0 . Digital input module DI 16×230 V AC, 16 channels in groups of 4; Input delay 20ms; Input type 1 (IEC 61131) | 6AG1521-1FH00-7AA0 |
| SIPLUS S7-1500 DI 16x 48VUC/ 125V -40…+70°C with conformal coating based on 6ES7521-7EH00-0AB0 . 16 channels in groups of 1; Input delay 0.05..20ms Input type 3 (IEC 61131); diagnostics; hardware interrupts | 6AG1521-7EH00-7AB0 |
| Module DO | |
| SIPLUS S7-1500 DQ 8×24 V DC/2A -40…+70°C with conformal coating based on 6ES7522-1BF00-0AB0 . Digital output module DQ 8×24 V DC/2A HF; 8 channels in groups of 8; 8 A per group; diagnostics; substitute value | 6AG1522-1BF00-7AB0 |
| SIPLUS S7-1500 DQ 16X24VDC/0.5A -40 … +70°C MIT conformal coating based on 6ES7522-1BH01-0AB0 . 16 CHANNELS IN GROUPS OF 8, 4 A PER GROUP; SINGLE-CHANNEL DIAGNOSIS; SUBSTITUTE VALUE | 6AG1522-1BH01-7AB0 |
| SIPLUS S7-1500 DQ 32x24VDC/0.5A -40 … +70°C with conformal coating based on 6ES7522-1BL01-0AB0 . 32 CHANNELS IN GROUPS OF 8, 4 A PER GROUP; SINGLE-CHANNEL DIAGNOSIS; SUBSTITUTE VALUE | 6AG1522-1BL01-7AB0 |
| SIPLUS S7-1500 DQ 16x48VUC/125V -40…+70°C with conformal coating based on 6ES7522-5EH00-0AB0 . DQ16x 24…48VUC/125V DC/0.5A; 16 channels in groups of 1; 0.5 A per group; Substitute value; Observe derating | 6AG1522-5EH00-7AB0 |
| SIPLUS S7-1500 DO 8x230V AC/2A -40…+70°C with conformal coating based on 6ES7522-5FF00-0AB0 . Digital output module DQ 8xAC 230V/2A; TRIAC; 8 channels in groups of 1; 2 A per group; Substitute value | 6AG1522-5FF00-7AB0 |
| SIPLUS S7-1500 16DQ 230VAC 1A ST TRIAC -40 … +70°C start up -25°C with conformal coating based on 6ES7522-5FH00-0AB0 . SIMATIC S7-1500, Digital output module DQ 16xAC 230V/1A; TRIAC; 16 channels in groups of 2; 2 A per group; Substitute value | 6AG1522-5FH00-7AB0 |
| SIPLUS S7-1500 DQ 8X230VAC/5A S -25 … +60°C with conformal coating based on 6ES7522-5HF00-0AB0 . DIGITAL OUTPUT MODULE DQ 8 X 230VAC/5A,RELAY; 8 CHANNELS IN GROUPS OF 1, 5A PER GROUP; DIAGNOSIS; SUBSTITUTE VALUE | 6AG1522-5HF00-2AB0 |
| SIPLUS S7-1500 16DQ 230VAC 2A RLY -40 … +70°C start up -25 °C with conformal coating based on 6ES7522-5HH00-0AB0. Digital output module DQ 16 X 230VAC / 2A ST; RELAY; 16 channels in groups of 2, 4A per group; Diagnosois; | 6AG1522-5HH00-7AB0 |
Module AI/AO cho S7-1500
Module AI/AO tiêu chuẩn
| Module AI | |
| SIMATIC S7-1500 analog input module AI 8xU/I/RTD/TC ST, 16 bit resolution, accuracy 0.3%, 8 channels in groups of 8; 4 channels for RTD measurement, common mode voltage 10 V; Diagnostics; Hardware interrupts; Delivery including infeed element, shield bracket and shield terminal: Front connector (screw terminals or push-in) to be ordered separately | 6ES7531-7KF00-0AB0 |
| SIMATIC S7-1500, analog input module AI 16xU BA, 16-bit resolution accuracy 0.5%, 16 channels in groups of 16, common mode voltage 4 V DC, diagnostics, hardware interrupts; delivery including infeed element, shield bracket and shield terminal: front connector (screw terminals or push-in) to be ordered separately | 6ES7531-7LH00-0AB0 |
| SIMATIC S7-1500, analog input module AI 16xI BA, 16-bit resolution accuracy 0.5%, 16 channels in groups of 16, common mode voltage 4 V DC, diagnostics, hardware interrupts; delivery including infeed element, shield bracket and shield terminal: front connector (screw terminals or push-in) to be ordered separately | 6ES7531-7MH00-0AB0 |
| SIMATIC S7-1500 analog input module AI 8xU/I HF, up to 24 bit resolution, accuracy 0.1%, 8 channels in groups of 1; common mode voltage: 30 V AC/60 V DC, Diagnostics; Hardware interrupts Measured values scalable, measuring range adjustment, Calibrate in RUN; Delivery including infeed element, shield bracket and shield terminal: Front connector (screw terminals or push-in) to be ordered separately | 6ES7531-7NF00-0AB0 |
| SIMATIC S7-1500 Analog input module AI 8xU/I HS, 16 bit resolution, Accuracy 0.3% 8 channels in groups of 8; Common mode voltage 10 V; Diagnostics; Hardware interrupts 8 channels in 0.0625 ms Oversampling; Delivery including infeed element, shield bracket and shield terminal: Front connector (screw terminals or push-in) to be ordered separately | 6ES7531-7NF10-0AB0 |
| SIMATIC S7-1500 analog input module AI 8xU/R/RTD/TC HF, 16 bit resolution, up to 21 bit Resolution at RT and TC, accuracy 0.1%, 8 channels in groups of 1; common mode voltage: 30 V AC/60 V DC, Diagnostics; Hardware interrupts Scalable temperature measuring range, thermocouple type C, Calibrate in RUN; Delivery including infeed element, shield bracket and shield terminal: Front connector (screw terminals or push-in) to be ordered separately | 6ES7531-7PF00-0AB0 |
| SIMATIC S7-1500 Analog input module AI 4xU/I/RTD/TC ST, 16 bit resolution, Accuracy 0.3%, 4 channels in groups of 4; 2 channels for RTD measurement; Common mode voltage 10 V; Diagnostics; Hardware interrupts; Delivery including push-in front connector, infeed element, shield bracket, and shield terminal | 6ES7531-7QD00-0AB0 |
| SIMATIC S7-1500 Analog input module, AI 8xU/I/R/RTD BA, 16 bit resolution, Accuracy 0.5%, 8 channels in groups of 8; Common mode voltage 4 V DC, Diagnostics; Hardware interrupts; Delivery including infeed element, shield bracket and shield terminal: Front connector (screw terminals or push-in) to be ordered separately | 6ES7531-7QF00-0AB0 |
| Module AO | |
| SIMATIC S7-1500, analog output module AQ 4xU/I ST, 16-bit resolution accuracy 0.3%. 4 channels in groups of 4, diagnostics; substitute value; the module supports the safety-oriented shutdown of load groups up to SILCL1 according to EN 62061:2005 + A2:2015, and Category 2 / PL c according to EN ISO 13849-1:2015. delivery including infeed element, shield bracket and shield terminal: front connector (screw terminals or push-in) to be ordered separately | 6ES7532-5HD00-0AB0 |
| SIMATIC S7-1500, analog output module AQ8xU/I HS, 16-bit resolution accuracy 0.3%, 8 channels in groups of 8, diagnostics; substitute value 8 channels in 0.125 ms oversampling; the module supports the safety-oriented shutdown of load groups up to SILCL2 acc. to EN 62061:2005 + A2:2015, and Category 3 / PL d according to EN ISO 13849-1:2015. delivery including infeed element, shield bracket and shield terminal: front connector (screw terminals or push-in) to be ordered separately | 6ES7532-5HF00-0AB0 |
| SIMATIC S7-1500, analog output module AQ 2x U/I ST, 16-bit resolution accuracy 0.3%. 2 channels in groups of 2, diagnostics; substitute value; the module supports the safety-oriented shutdown of load groups up to SILCL1 according to EN 62061:2005 + A2:2015, and Category 2 / PL c according to EN ISO 13849-1:2015. delivery including front connector push-in, infeed element, shield bracket and shield terminal | 6ES7532-5NB00-0AB0 |
| SIMATIC S7-1500, analog output module AQ 4xU/I HF, 16-bit resolution accuracy 0.1%, 4 channels in groups of 1, common mode voltage: 30 V AC/60 V DC, diagnostics; substitute value, isochronous mode; the module supports the safety-oriented shutdown of load groups up to SILCL2 acc. to EN 62061:2005 + A2:2015, and Category 3 / PL d according to EN ISO 13849-1:2015. delivery including infeed element, shield bracket and shield terminal: front connector (screw terminals or push-in) to be ordered separately | 6ES7532-5ND00-0AB0 |
| Module AI/AO | |
| SIMATIC S7-1500 Analog input/output module AI 4x U/I/R/RTD/TC ST; 4 channels in groups of 4; Hardware interrupts; Diagnostics AQ 2x U/I ST; 2 channels in groups of 2; Substitute value; Diagnostics Common mode voltage approx. 10 V 16 bit; Accuracy 0.3%; Delivery including push-in front connector, infeed element, shield bracket and shield terminal | 6ES7534-7QE00-0AB0 |
SIPLUS Module AI/AO
| Module AI | |
| SIPLUS S7-1500 AI 8xU/I/RTD/TC -40°C … +70°C with conformal coating based on 6ES7531-7KF00-0AB0 . Analog input module 16 bit resolution, Accuracy 0.3%, 8 channels in groups of 8, Common mode voltage 10 V; diagnostics; hardware interrupts incl. infeed element, Shield bracket and shield terminal | 6AG1531-7KF00-7AB0 |
| SIPLUS S7-1500 AI 8XU/I HF -40 … +70°C with conformal coating based on 6ES7531-7NF00-0AB0 . 16 bit resolution, Accuracy 0.1%, 8 channels in groups of 1, Common mode voltage: 30V AC/60V DC, diagnostics; hardware interrupts; incl. infeed element, Shield bracket and shield terminal | 6AG1531-7NF00-7AB0 |
| SIPLUS S7-1500 AI 8xU/I HS -40 °C … +70°C with conformal coating based on 6ES7531-7NF10-0AB0 . Analog input module AI 8xU/I HS, 16 bit resolution, Accuracy 0.4% 8 channels in groups of 8, Common mode voltage 10 V; diagnostics; hardware interrupts 8 channels in 0.125 ms incl. infeed element, Shield bracket and shield terminal | 6AG1531-7NF10-7AB0 |
| SIPLUS S7-1500 AI 8XU/R/RTD/TC HF 0 … +60°C with conformal coating based on 6ES7531-7PF00-0AB0 . Analog Input Module AI 8 X U/R/RTD/TC HF, 16 BITS OF RESOLUTION, Accuracy 0.1%, 8 Channels in groups of 1; common mode Voltage: 30 V AC/60 V DC, Diagnosis, Process alarms; incl. infeed element, Shield clamp and Shield terminal | 6AG1531-7PF00-4AB0 |
| Module AO | |
| SIPLUS S7-1500 AO 4xU/I ST -40 °C … +70°C with conformal coating based on 6ES7532-5HD00-0AB0 . Analog output module 16 bit resolution, Accuracy 0.3%. 4 channels in groups of 4, diagnostics; substitute value incl. infeed element, shield bracket and shield terminal | 6AG1532-5HD00-7AB0 |
| SIPLUS S7-1500 AQ 8xU/I HS -40…+70 °C Start up -25 °C with conformal coating based on 6ES7532-5HF00-0AB0 . Analog output module AQ8xU/I HS, 16 bit resolution, Accuracy 0.4%, 8 channels in groups of 8, diagnostics; substitute value 8 channels in 0.125 ms incl. infeed element, Shield bracket and shield terminal | 6AG1532-5HF00-7AB0 |
Technology modules
Technology modules tiêu chuẩn
| SIMATIC S7-1500, TM count 2x24V Counter module, 2 channels for 24 V incremental or encoder 3 DI, 2 DQ per channel | 6ES7550-1AA00-0AB0 |
| SIMATIC S7-1500, TM count 2x 24 V counter module, 2 channels for 24 V incremental encoder or pulse encoder, 3 DI, 2 DQ per channel | 6ES7550-1AA01-0AB0 |
| SIMATIC S7-1500, TM POSINPUT 2 Counter and position detection module for RS422 incremental encoder or SSI absolute value encoder, 2 channels, 2 DI, 2 DQ per channel | 6ES7551-1AB00-0AB0 |
| SIMATIC S7-1500, TM Timer DIDQ 16x 24 V time-controlled digital inputs and outputs max. 8 DI, 16 DQ of which max. 16 with time stamp, Count, PWM, oversampling | 6ES7552-1AA00-0AB0 |
| SIMATIC S7-1500, TM PTO 4 Interface board for stepper drives 4 Channels Pulse Train output PTO: 24 V, 2 DI, 1 DQ 24VDC per channel | 6ES7553-1AA00-0AB0 |
| SIWAREX WP521 ST WEIGHING ELECTRONIC (1 CHANNEL) FOR STRAIN GAUGE LOAD CELLS / FULL BRIDGES (1-4 mV/V) FOR SIMATIC S7-1500, RS485 AND ETHERNET-INTERFACE, ONBOARD I/O: DI 3 X 24V DC / DQ 4 X 24V DC | 7MH4980-1AA01 |
| SIWAREX WP522 ST WEIGHING ELECTRONIC (2 CHANNELS) FOR STRAIN GAUGE LOAD CELLS / FULL BRIDGES (1-4 mV/V) FOR SIMATIC S7-1500, RS485 AND ETHERNET-INTERFACE, ONBOARD I/O PER CHANNEL: DI 3 X 24V DC / DQ 4 X 24V DC | 7MH4980-2AA01 |
SIPLUS Technology modules
| SIPLUS S7-1500 TM Count 2x24V -40…+70°C with conformal coating based on 6ES7550-1AA00-0AB0 . Counter module, 2 channels for 24 V incremental or encoder 3 DI, 2 DQ per channel | 6AG1550-1AA00-7AB0 |
| SIPLUS S7-1500 TM POSINPUT 2 -40…+70°C start up -25°C with conformal coating based on 6ES7551-1AB00-0AB0 . Counting and position feedback module, 2 channels, for RS422 incremental encoder or SSI absolute value encoder, 2 DI, 2 DQ per channel | 6AG1551-1AB00-7AB0 |
Communication modules
- Serial communication
- IO Link Master
- Ethernet/PROFINET
- PROFIBUS
Communication module tiêu chuẩn
| SIMATIC S7-1500, CM PTP RS422/485 BA Communication module for Serial connection RS422,RS485 Freeport, 3964 (R), USS, 19200 Kbit/s, 15-Pin D-sub socket | 6ES7540-1AB00-0AA0 |
| SIMATIC S7-1500, CM PTP RS232 BA Communication module for Serial connection RS232, Freeport, 3964 (R), USS, 19200 Kbit/s, 9-pin D-sub connector | 6ES7540-1AD00-0AA0 |
| SIMATIC S7-1500, CM PTP RS422/485 HF Communication module for Serial connection RS422 and RS485, Freeport, 3964 (R), USS, MODBUS RTU Master, Slave, 115200 Kbit/s, 15-Pin D-sub socket | 6ES7541-1AB00-0AB0 |
| SIMATIC S7-1500, CM PTP RS232 HF Communication module for Serial connection RS232, Freeport, 3964 (R), USS, MODBUS RTU Master, Slave, 115200 Kbit/s, 9-pin D-sub connector | 6ES7541-1AD00-0AB0 |
| S7-1500, CM 8xIO-Link, communication module IO-Link Master V1.1; Front connector (screw terminals or push-in) to be ordered separately | 6ES7547-1JF00-0AB0 |
| Communication module CM 1542-5 for connection of S7-1500 to PROFIBUS DP, DPV1 master or DP slave, S7 and PG/OP communication, data record routing, time-of-day synchronization, Diagnostics | 6GK7542-5DX00-0XE0 |
| Communications processor CP 1542-5 for connection of SIMATIC S7-1500 to PROFIBUS DP, DPV1 master or DP slave, S7 and PG/OP communication, time-of-day synchronization, diagnostics, reduced quantity structure | 6GK7542-5FX00-0XE0 |
| Communication module CM 1542-1 for connection of S7-1500 to PROFINET as IO controller: TCP/IP, ISO-on-TCP, UDP, S7 communication, IP broadcast Multicast, SNMPV1, time-of-day synchronization via NTP, 2xRJ45 (10/100 Mbit) | 6GK7542-1AX00-0XE0 |
| Communications processor CP 1543-1 for connection of SIMATIC S7-1500 to Industrial Ethernet; TCP/IP, ISO, UDP, S7 communication, IP Broadcast/ Multicast, security (VPN, Firewall) Diagnostics SNMPV1/V3, DHCP, FTP client/server, Email, IPv4/IPv6, Time synchronization via NTP, 1x RJ45 (10/100/1000 MB) | 6GK7543-1AX00-0XE0 |
| Communications processor CP 1545-1 for connection of SIMATIC S7-1500 to Industrial Ethernet; TCP/IP, UDP, S7 communication, Security (firewall), SNMPv1/v3, DHCP, FTP client/server, email, IPv4/IPv6, time-of-day synchronization via NTP, connection to cloud systems via MQTT, 1x RJ45 (10/100/1000 Mbps) | 6GK7545-1GX00-0XE0 |
| TIM 1531 IRC Communications module for SIMATIC S7-1500, S7-400, S7-300 with SINAUT ST7, DNP3 and IEC 60870-5-101/104 with three RJ45 interfaces for communication via IP-based networks (WAN / LAN) and a RS 232/RS 485 interface for communication via classic WAN networks | 6GK7543-1MX00-0XE0 |
| IWLAN Access Point, SCALANCE W774-1 RJ45, 1 radio, 2 R-SMA antenna port, iFeatures support via key plug, IEEE 802.11a/b/g/h/n, 2.4/5GHz, gross data rate 300 Mbit/s, 2x RJ45 max. 100 Mbit/s, PoE integrated 2-port switch, redundant 24 V DC, terminal block, IP30, -20… 60 °C, plug slot WPA2/802.11i/e, observe national approvals! CERT ID: MSN-W1-RJ-E2, scope of delivery: Manuals on CD-ROM, German/English, 1x terminal block; for operation outside of USA/Israel | 6GK5774-1FX00-0AA0 |
| IWLAN Access Point, SCALANCE W774-1 RJ45, 1 radio, 2 R-SMA antenna port, iFeatures support via key plug, IEEE 802.11a/b/g/h/n, 2.4/5GHz, gross data rate 300 Mbit/s, 2x RJ45 max. 100 Mbit/s, PoE integrated 2-port switch, redundant 24 V DC, terminal block, IP30, -20… 60 °C, plug slot WPA2/802.11i/e, observe national approvals! CERT ID: MSN-W1-RJ-E2, scope of delivery: Manuals on CD-ROM, German/English, 1x terminal block; for operation in the USA | 6GK5774-1FX00-0AB0 |
| IWLAN Access Point, SCALANCE W774-1 RJ45, 1 radio, 2 R-SMA antenna port, iFeatures support via key plug, IEEE 802.11a/b/g/h/n, 2.4/5GHz, gross data rate 300 Mbit/s, 2x RJ45 max. 100 Mbit/s, PoE integrated 2-port switch, redundant 24 V DC, terminal block, IP30, -20… 60 °C, plug slot WPA2/802.11i/e, observe national approvals! CERT ID: MSN-W1-RJ-E2, scope of delivery: Manuals on CD-ROM, German/English, 1x terminal block; for operation in Israel | 6GK5774-1FX00-0AC0 |
| IWLAN client, SCALANCE W734-1, RJ45, 1 radio, 2 R-SMA antenna port, iFeatures support via key plug, IEEE 802.11a/b/g/h/n, 2.4/5GHz, gross data rate 300 Mbit/s, 2x RJ45 max. 100 Mbit/s, PoE integrated 2-port switch, redundant 24 V DC, terminal block, IP30, -20… 60 °C, plug slot WPA2/802.11i/e, observe national approvals! CERT ID: MSN-W1-RJ-E2, scope of delivery: Manuals on CD-ROM, German/English, 1x terminal block; for operation outside of USA/Israel | 6GK5734-1FX00-0AA0 |
| IWLAN client, SCALANCE W734-1, RJ45, 1 radio, 2 R-SMA antenna port, iFeatures support via key plug, IEEE 802.11a/b/g/h/n, 2.4/5GHz, gross data rate 300 Mbit/s, 2x RJ45 max. 100 Mbit/s, PoE integrated 2-port switch, redundant 24 V DC, terminal block, IP30, -20… 60 °C, plug slot WPA2/802.11i/e, observe national approvals! CERT ID: MSN-W1-RJ-E2, scope of delivery: Manuals on CD-ROM, German/English, 1x terminal block; only for operation in USA | 6GK5734-1FX00-0AB0 |
| Engineering Software | |
| SIMATIC STEP 7 Basic V15.1; Upgrade V11..V14-> V15.1 Floating License; Engineering Software in TIA Portal; SW and documentation on DVD; License key on USB flash drive; Class A; 6 languages: de,en,fr,es,it,zh; Executable in Windows 7 (64-bit), Windows 10 (64-bit), Windows Server 2012R2 (64-bit), Windows Server 2016 (64 bit); for configuration of SIMATIC S7-1200 SIMATIC Basic Panels * Content: Set (5x DVD + 1x USB) | 6ES7822-0AA05-0YE5 |
| SIMATIC STEP 7 Prof. V15.1; Floating License; Engineering Software in TIA Portal; SW and documentation on DVD; license key on USB flash drive; Class A; 6 languages: de,en,fr,es,it,zh; Executable in Windows 7 (64-bit), Windows 10 (64-bit), Windows Server 2012R2 (64-bit), Windows Server 2016 (64 bit); for configuration of SIMATIC S7-1200/1500, SIMATIC S7-300/400/WinAC, SIMATIC Basic Panels * Content: Set (3x DVD + 1x USB) | 6ES7822-1AA05-0YA5 |
| SIMATIC STEP 7 Prof. V15.1 Upgrade V11..V14-> V15.1 or V11/2010..V14/2017 -> V15.1/2017 SR1 or 2006..2010-> V15.1/2017 SR1 Combo Floating License; Engineering Software in the TIA Portal; also applies for upgrade from V11 Single licenses; SW and documentation on DVD; license keys on USB flash drive; Class A; 6 languages: de,en,fr,es,it,zh; Executable in Windows 7(64 bit), Windows 10 (64-bit), Windows Server 2012/16 (64); for configuring of SIMATIC S7-1200/1500, S7-300/400/WinAC, SIMATIC Basic Panels * Content: Set (6x DVD + 1x USB) | 6ES7822-1AA05-0YE5 |
SIPLUS Communication modules
| SIPLUS S7-1500CM PtP RS422/485 -40…+70°C start up -25°C with conformal coating based on 6ES7540-1AB00-0AA0 . Communication module for Serial connection RS422, RS485 Freeport, 3964 (R), USS, 19200 Kbit/s, 15-Pin D-sub socket | 6AG1540-1AB00-7AA0 |
| SIPLUS S7-1500cm PtP RS232 BA -40…+70°C start up -25°C with conformal coating based on 6ES7540-1AD00-0AA0 . Communication module for Serial connection RS232, Freeport, 3964 (R), USS, 19200 Kbit/s, 9-pin D-sub connector | 6AG1540-1AD00-7AA0 |
| SIPLUS S7-1500CM PtP RS422/485 -40…+70°C start up -25°C with conformal coating based on 6ES7541-1AB00-0AB0 . Communication module for Serial connection RS422 and RS485, Freeport, 3964 (R), USS, MODBUS RTU Master, Slave, 115200 Kbit/s, 15-Pin D-sub socket | 6AG1541-1AB00-7AB0 |
| SIPLUS S7-1500 CM PtP RS232 HF -40…+70°C start up -25°C with conformal coating based on 6ES7541-1AD00-0AB0 . Communication module for Serial connection RS232, Freeport, 3964 (R), USS, MODBUS RTU Master, Slave, 115200 Kbit/s, 9-pin D-sub connector | 6AG1541-1AD00-7AB0 |
| SIPLUS NET CM 1542-5 (Profibus -40…+70°C with conformal coating based on 6GK7542-5DX00-0XE0 . Communication module for connection of S7-1500 to PROFIBUS DP as DP master and DP slave: S7 and PG/OP communication, time-of-day synchronization, Diagnostics | 6AG1542-5DX00-7XE0 |
| SIPLUS CP 1543-1 -40…+70 °C with conformal coating based on 6GK7543-1AX00-0XE0 Communications processor for connecting SIMATIC S7-1500 to Industrial Ethernet: TCP/IP, ISO, UDP, S7 communication, IP Broadcast/ Multicast, security (hardware identification, IP/MAC access list, firewall), Diagnostics SNMPV1/V3, DHCP, FTP client/ server, E-mail, IPV4/IPV6, Data storage on SD card of the CPU, time-of-day synchronization via NTP, Access to the Web server of the CPU; Gigabit interface 1x RJ45 (10/100/1000 MB) | 6AG1543-1AX00-2XE0 |
Fail-safe I/O module
| SIMATIC S7-1500, F digital input module, F-DI 16x 24 V DC PROFIsafe; 35 mm width; up to PL E (ISO 13849-1)/ SIL 3 (IEC 61508) | 6ES7526-1BH00-0AB0 |
| SIMATIC S7-1500, F digital output module, F-DQ 8x 24 V DC 2A PPM PROFIsafe; 35 mm width; up to PL E (ISO 13849-1)/ SIL3 (IEC 61508) | 6ES7526-2BF00-0AB0 |
| SIPLUS S7-1500 F-DI 16x24VDC -30 … +60°C with conformal coating based on 6ES7526-1BH00-0AB0 . FAILSAFE DIGITAL INPUT MODULE, F-DI 16X24VDC PROFISAFE; 35 MM WIDTH; UP TO PL E (ISO 13849-1)/ SIL3 (IEC 61508) | 6AG1526-1BH00-2AB0 |
| SIPLUS S7-1500 F-DQ 8x24VDC/2A -30 … +60°C with conformal coating based on 6ES7526-2BF00-0AB0 . F DIGITAL OUTPUT MODULE, F-DQ 8X24VDC 2A PPM PROFISAFE; 35 mm overall width; UP TO PL E (ISO 13849-1)/ SIL3 (IEC 61508) | 6AG1526-2BF00-2AB0 |
Trên đây, MC&TT đã tổng hợp những thông tin cần thiết về SIMATIC S7-1500 của Siemens. Hy vọng rằng, với những chia sẻ phía trên sẽ giúp ích cho các bạn đang tìm hiểu, học tập hay làm việc với PLC S7-1500. Xin cảm ơn!
